Full Color Outdoor Advertising Screen Display LED 320x160mm
Nationstar Full Color Double Pillar Type 5mm Rgb Led Advertising Panel
Product description
1. 3 seconds lock type installation to complete a module, save the cost of manual installation, improve work efficiency, easy maintenance.
2. By computer, wifi, 4G, usb, remote, internet, mobile, pad, etc. Yes, you can control in your convenient management. Many screens together? No problem, your laptop can manage all of them whenever and wherever.
3. The unique triple brim design can effectively block direct light while protecting the screen, and at the same time prevent the reflection of strong light on the LED screen. This design further enhances the contrast on the conventional basis, giving the picture quality a sense of hierarchy.
4. From the overall layout of PCB design, the product strictly follows the design standards of EMC testing, and has the performance that can withstand higher standards of electromagnetic compatibility testing. Every detail is to improve the overall stability of the display device.
5. High refresh, high grey scale and high brightness.
6. The heat dissipation capacity is 10 times that of the traditional iron/steel cabinet, and the cabinet itself is the first level of heat
dissipation.
Pixel Pitch | 10mm | |||
LED Lamp | SMD3535 | |||
LED configuration | SMD 3 in 1 | |||
Module Size | 320mm x 160mm | |||
Module pixels | 32x16dots | |||
Cabinet Size(WxHxD)(mm) | 960x960x108mm | |||
Module Quantity(pcs) | 18 | |||
Cabinet resolution WxH | 96x96dots | |||
Cabinet Material | magnesium alloy | |||
Cabinet Weight (kg) | 29 | |||
Average Power/sqm (watts) | 240 | |||
Max Power/sqm(watts) | 800 | |||
Brightness | 6500cd/㎡ | |||
Viewing Angle | H:160°, V:120° | |||
Best Viewing Distance | 10-200 meters | |||
Brightness Control | 256 level | |||
Gray scale | 14 bit | |||
Refresh frequency | 1920hertz | |||
Driving mode | 1/2 scan | |||
Input power frequency | 50 or 60 Hertz | |||
Input Voltage | 110 ~ 240 Volt,60Hz | |||
Blind spot rate | <1/10000 | |||
Lifetime at 50% brightness | 100000 hours | |||
Ingress Protection | IP65 | |||
Operating temperature | ﹣20 ~﹢60 ℃ | |||
Operating humidity | 10% ~ 90% | |||
Control distance | CAT5 cable:<100 m; Single mode fiber:<10 km | |||
Signal input format | HDMI,DVI,SDI,VGA etc. | |||
Operating system | Windows (2000/XP/Vista/7/8/10) |
FAQ
Q: Are you manufacturer or trade company?
A: We are manufacturer,
Q: Do you offer OEM&ODM service?
A: Yes, we do.
Q: What’s the quality standard of your products?
A: Our products has approved CCC, ISO9001, CE, RoHS certification.
Q: Which place will use ITC equipment?
A: Our products are widely used in International Conferences, Governments,Banks,Churches, Highways,Airports,Parliaments,Education institutes,Hotel,Private corporate conference hall and so on.
Q: What project did you have done in overseas?
A: 2017, MPLED P6 outdoor led display assist for Senator Election of South Korea
2018, MPLED P10 outdoor led display light up in The World Cup in Russia
2019, MPLED P2.97 stage led display stand the stage for Senator Election of Indonesia
2020, MPLED P1.86 led display(more than 150sq.m) install in Singapore Casino
2020, MPLED P3 led display covered the SAINT PHILA CONVENTION HALL
2021, MPLED P8 outdoor customized wave led display light up in Kuwait landmark
