IP65 waterproof Outdoor P10 LED Screen Energy Saving Environmental Protection
IP65 waterproof Outdoor P10 LED Screen Energy Saving Environmental Protection
IP65 waterproof Outdoor P10 LED Screen Energy Saving Environmental Protection
IP65 waterproof Outdoor P10 LED Screen Energy Saving Environmental Protection
Specifications
Brand Name :
MPLED
Model Number :
P10
Certification :
CE/ROHS/FCC/ISO/UL
Place of Origin :
China
MOQ :
1
Price :
USD+620-750+pcs
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
3000sqm
Delivery Time :
7-10 working days after receive your payment
Packaging Details :
flight case/ wooden case/ carton/ it is up to you
Product name :
advertising display screen
Product :
digital advertising screen
name :
advertising led display
the name or description of a commodity :
led display price
Brand naming :
led video wall panel
Name of commodity :
3d led screen outdoor
Description

energy saving environmental protection outdoor p10 led screen

Product description

1. There are quick locks on the top and bottom and left and right sides of the box. Installation is faster. Better flatness and consistency.

2. Super heat dissipation, Super waterproof

3. Cold screen, high efficiency, environmental protection and energy saving

4. P2.5 P3 P4 P5 P6 P8 P10(320x160mm) can be replaced directly.

5. Including power supply, boards, cables, modules, and at the same time meet the front and rear maintenance

6. IP65 waterproof level can ensure stable operation of the screen even in extreme weather below:Typhoon,Rainstorm ,High Temperature ,Low Temperature ,High Humidity ,Salt Spray.

7. The module supports front/rear maintenance to meet the needs of more installation environments

8. Fanless design prevents dust and water vapor from being brought into the cabinet.

Pixel Pitch 10mm
LED Lamp SMD3535
LED configuration SMD 3 in 1
Module Size 320mm x 160mm
Module pixels 32x16dots
Cabinet Size(WxHxD)(mm) 960x960x101mm
Module Quantity(pcs) 18
Pixel Density 96x96dots
Cabinet pixels 9216 dots
Cabinet Material Magnesium alloy
Cabinet Weight (kg) 25
Average Power/sqm (watts) 200
Max Power/sqm(watts) 600
Brightness 7000-7500cd/㎡
Viewing Angle H:160°, V:120°
Best Viewing Distance 10-100 meters
Brightness Control 256 level
Gray scale 14 bit
Refresh frequency 1920hertz
Driving mode 1/2 scan
Input power frequency 50 or 60 Hertz
Input Voltage 110 ～ 240 Volt,60Hz
Blind spot rate ＜1/10000
Lifetime at 50% brightness 100000 hours
Ingress Protection IP65
Operating temperature ﹣20 ～﹢60 ℃
Operating humidity 10％ ～ 90％
Control distance CAT5 cable:＜100 m; Single mode fiber:＜10 km
Signal input format HDMI,DVI,SDI,VGA etc.

IP65 waterproof Outdoor P10 LED Screen Energy Saving Environmental ProtectionIP65 waterproof Outdoor P10 LED Screen Energy Saving Environmental Protection
