P4 Outdoor Concert LED Screen Rental Displays High Resolution Die Casting Aluminum
outdoor nationstar p4.81 500x500mm die-cast rental curved led display
Product presentation
1. High end aluminum base stacking, Wall mounting , Structure for wall mounting, Steel base stacking
2. Tempered glass design for gorgeous and shining effect,The surface is made of highly polished deep black tempered glass, which is easy to clean.
3. Module/PSU directly mounted onto frame,Potential for future upgrade.
4. Super strong anti-UV, anti-level 12 storm, anti-severe cold, corrosion resistance, adapt to various harsh environments.
5. High IP65 Waterproof with Double Sealing Rubber Ring.
6. By computer, wifi, 4G, usb, remote, internet, mobile, pad, etc. Yes, you can control in your convenient management. Many screens together? No problem, your laptop can manage all of them whenever and wherever.
Pixel Pitch | 4.81mm |
LED Lamp | SMD1921 |
IC | ICN2153 |
Module Size | 250x250mm |
Module pixels | 52x52 dots |
Cabinet Size(WxHxD)(mm) | 500x1000x88 mm |
Module Quantity(pcs) | 8 |
Cabinet resolution WxH | 104x208dots |
Cabinet Material | Aluminum die casting |
Cabinet Weight (kg) | 14 |
Average Power/sqm (watts) | 200 |
Max Power/sqm(watts) | 650 |
Brightness | 4500-5000cd/㎡ |
Viewing Angle | H:160°, V:120° |
Best Viewing Distance | 3.91-200 meters |
Brightness Control | 256 level |
Gray scale | 16 bit |
Refresh frequency | 3840hertz |
Driving mode | 1/13 scan |
Input power frequency | 50 or 60 Hertz |
Input Voltage | 110 ~ 240 Volt,60Hz |
Blind spot rate | <1/10000 |
Lifetime at 50% brightness | 100000 hours |
Ingress Protection | IP65 |
Operating temperature | ﹣20 ~﹢60 ℃ |
Operating humidity | 10% ~ 90% |
Control distance | CAT5 cable:<100 m; Single mode fiber:<10 km |
Signal input format | HDMI,DVI,SDI,VGA etc. |
Operating system | Windows (2000/XP/Vista/7/8/10) |
FAQ
Q: What’s the quality standard of your products?
A: Our products has approved CCC, ISO9001, CE, RoHS certification.
Q: How about your warranty?
A: Different product offer different time frame warranty, but all product here we offer 2year at least warranty.
Q: Which place will use ITC equipment?
A: Our products are widely used in International Conferences, Governments,Banks,Churches, Highways,Airports,Parliaments,Education institutes,Hotel,Private corporate conference hall and so on.
Q:How about your delivery time?
A:Generally. it will take 15 to 25 days after receiving your advance payment. The spe- cific delivery time depends on the items and the quantity of your order.
Q: What project did you have done in overseas?
A: 2017, MPLED P6 outdoor led display assist for Senator Election of South Korea
2018, MPLED P10 outdoor led display light up in The World Cup in Russia
2019, MPLED P2.97 stage led display stand the stage for Senator Election of Indonesia
2020, MPLED P1.86 led display(more than 150sq.m) install in Singapore Casino
2020, MPLED P3 led display covered the SAINT PHILA CONVENTION HALL
2021, MPLED P8 outdoor customized wave led display light up in Kuwait landmark
