Die Casting Aluminium Cabinet Smd Panel Outdoor Rental LED Display Waterproof
Die Casting Aluminium Cabinet Smd Panel Outdoor Rental LED Display Waterproof
Die Casting Aluminium Cabinet Smd Panel Outdoor Rental LED Display Waterproof
Die Casting Aluminium Cabinet Smd Panel Outdoor Rental LED Display Waterproof
Specifications
Brand Name :
MPLED
Model Number :
P3.91
Certification :
CE/ROHS/FCC/ISO/UL
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
3000sqm
Delivery Time :
7-10 working days after receive your payment
Packaging Details :
flight case/ wooden case/ carton/ it is up to you
Product name :
Outdoor Rental LED Display
Pixels :
3.91mm
Screen dimension :
500x1000mm
Brightness :
1200cd/m²
Warranty :
2 Years
Description

Die Casting Aluminium Cabinet Smd Panel Outdoor Rental LED Display

product presentation

1. 500*500mm and 500*1000mm standard cabinet size Ultra-Light die-casting aluminum. ultra-thin thickness with 80mm.For easy transport and Portable.

2. Adopts magnetic adsorption LED panels with ultra thin design, broadside waterproof interface and installation knob.Fast replacement, assemble, disassemble with safety protection.

3. High-intensity frame, strong load capacity.

4. Hard Connection Design with detachable Power box and HUB Poard,

5.Advanced Inner and outer curve lock systems,Two side locks, with angles of -7.5 ° , -5°, -2.5°, 0°,+2.5°, +5°, 7.5°, +10 ° screen

6. Wind-resistant Design wind bracing for fresh gale level 8 when hanged 10m high

Pixel Pitch 3.91mm
LED Lamp SMD2121
IC ICN2153
Module Size 250x250mm
Module pixels 64x64 dots
Cabinet Size(WxHxD)(mm) 500x1000x88 mm
Module Quantity(pcs) 8
Cabinet resolution WxH 128x256dots
Cabinet Material Aluminum die casting
Cabinet Weight (kg) 14
Average Power/sqm (watts) 200
Max Power/sqm(watts) 650
Brightness 1200cd/㎡
Viewing Angle H:160°, V:120°
Best Viewing Distance 3.91-200 meters
Brightness Control 256 level
Gray scale 16 bit
Refresh frequency 1920hertz
Driving mode 1/16 scan
Input power frequency 50 or 60 Hertz
Input Voltage 110 ～ 240 Volt,60Hz
Blind spot rate ＜1/10000
Lifetime at 50% brightness 100000 hours
Ingress Protection IP30
Operating temperature ﹣20 ～﹢60 ℃
Operating humidity 10％ ～ 90％
Control distance CAT5 cable:＜100 m; Single mode fiber:＜10 km
Signal input format HDMI,DVI,SDI,VGA etc.
Operating system Windows (2000/XP/Vista/7/8/10)

Die Casting Aluminium Cabinet Smd Panel Outdoor Rental LED Display WaterproofDie Casting Aluminium Cabinet Smd Panel Outdoor Rental LED Display Waterproof

FAQ

Q: Are you manufacturer or trade company?
A: We are manufacturer,

Q: Do you offer OEM&ODM service?
A: Yes, we do.

Q: What’s the quality standard of your products?
A: Our products has approved CCC, ISO9001, CE, RoHS certification.

Q: Which place will use ITC equipment?
A: Our products are widely used in International Conferences, Governments,Banks,Churches, Highways,Airports,Parliaments,Education institutes,Hotel,Private corporate conference hall and so on.

Q: What project did you have done in overseas?
A: 2017, MPLED P6 outdoor led display assist for Senator Election of South Korea

2018, MPLED P10 outdoor led display light up in The World Cup in Russia

2019, MPLED P2.97 stage led display stand the stage for Senator Election of Indonesia

2020, MPLED P1.86 led display(more than 150sq.m) install in Singapore Casino

2020, MPLED P3 led display covered the SAINT PHILA CONVENTION HALL

2021, MPLED P8 outdoor customized wave led display light up in Kuwait landmark
