Outdoor Football Stadium Perimeter Sports Ground Waterproof P10 Led Display
Product Feature
1. OEM cabinet size: cabinet size is adjustable and compatible with different pixels.
2. Screen can work under very strong sunlight.
3. Outdoor standard cabinet applied with strong humidity resistance ability as well as corrossion resistance.
4. Wide vertical and horizontal viewing angle, broadcast-level color gamut, CT and brightness adjustable, more appropiatefor long-time watching.
5. It is manufactured as per latest dynamic scanning mode technology which offers higher brightness and high refresh rate. It features a high refresh rate of 3840Hz or higher, producing best quality outputs in form of pictures, videos and texts.
6. Smooth display image is realized shooting with 3840HZ refresh rate even under 1/2000 shutter professional camera shooting fully meeting the demand of live feed switching with no flicker.
FREQUENCY ASKED QUESTIONS
Q:Are you a factory or trading company?
A:We are a factory with 10+ years experience in led display industry. We can offer better price than trading Company.
Q: Where is your factory located? How can I visit there?
A: Our factory address is: B block, NO.56 Heng dong ling Industrial Zone, Shenzhen, China. We can pick you up from airport or your hotel for visiting.
Q: How to get the price list?
A: Sorry that we don't have price list because each project has difference requirements, and we quote according to your detailed requirements.
Q: Do you have any MOQ limit for led light order?
A: NO MOQ, 1pc for sample checking is available.
Q: How to proceed an order for led Dispaly?
A: Firstly let us know your requirements or application. Secondly we quote according to your requirements or our suggestions. Thirdly customer confirms the samples and places deposit for formal order. Fourthly we arrange the production.
Q: Is it OK to print my logo on cabinet?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
OUTDOOR FIXED | |||||||
Item | Value | ||||||
Model NO. | CDN-400 | CDN-500 | CDN-600 | CDN-800 | CDN-100 | CDN-100D | CDN-160D |
Pixel Pitch | 4 | 5 | 6 | 8 | 10 | 10 | 16 |
Pixel Density (dots/sqm) | 62500 | 40000 | 27777 | 15625 | 10000 | 10000 | 3906 |
LED Type | SMD1921 | SMD2727 | SMD3535 | DIP346 | |||
Viewing Angle | H:120 V:120 | H:120 V:60 | |||||
Brightness (nits) | 5000~6500 | 7000~8000 | |||||
Refresh Rate | 360~1920 | ||||||
Module Size(mm) | 256*128 | 160*160 | 192*192 | 256*128 | 320*160 | 160*160 | 256*256 |
Cabinet Size Recommended (mm) | 768*768 | 960*960 | 1024*1024 | 960*960 | 1024*1024 | ||
Cabinet Material | Steel with powder painted | ||||||
Cabinet Weight | ≈ 45KG/SQM | ||||||
Power Consumption (Avg./Max. W/㎡) | 360/900 | 400/980 | 240/600 | 280/700 | 400/980 | 300/760 | 180/550 |
IP Grade | IP65/54 | ||||||
Operating Temp/Humidity | -20℃~45℃ 10~90%RH | ||||||
Storage Temp/Humidity | -25℃~50℃ 10~90%RH | ||||||
Lifetime(hours) | ≥50000(Nomal Temp) |
Why choose us?
1. Diversified products: Varieties of models for outdoor/indoor LED display screens, and customized cabinets available, meet all requirements and win more profits for customers.
2. Quality assurance: Quality control is taken both in product design and production. As the quantity of PCB and other components have been decreased and simplified. Our engineers can concern in a small quantity of defect to solve and it will be a substantial boost of the yield rate. 100% testing before packing make sure our quality before delivery.
3. Best raw materials: High quality, good stability and reliability.
4. Competitive price: Factory price which is competitive in the market.
5. Prompt &Professional service: Any inquires will be replied within 12 hours in working days and you’ll get helpful suggestions from us.
The products we offer
Indoor fixed and rental: P1.667,P1.923,P2,P2.5,P3,P4,P5,P6,P3.91,P,4.81 P6.25,P7.62,P10
Outdoor fixed and rental: P3,P4,P5,P6,P3.91,P,4.81 P6.25,P8,P10,P12,P16,P20
Mobile truck led display, transparent glass window led display.creative led display (ball led display, dj led display) and other customerized led display products
Our Services
Pre-producing:
1. Get complete requirements of clients.
2. To do a thorough analysis.
3. Offer a most reasonable and scientific solution.
4. Customized design.
In producing:
1. Producing progress updating for clients.
2. Provide Installation drawing for clients.
After service:
1. 2 years free maintenance.
2. 7 days a week, 24 hours a day on-line technical support for any clients.
3. Free training for customers in factory.
4. Local Installation Guidance Service.
