P1.2 P 1.5 P1.9 Fine Pixel Pitch Led Screen Hd Indoor Hire Led Display Cabinet
Product features:
1. Neat appearance,light weight,small size and safe 5V low voltage power supply system all make the module more attractive.
2. Special walldrape design, no need buy more structure for installation.
3. Fast installation and front maintenance design is available, make your LED display business more proffessional and easier.
4. Screen can work under very strong sunlight.
5. Outdoor standard cabinet applied with strong humidity resistance ability as well as corrossion resistance.
6. Led display works in good condition under all kinds of bad weather; strong durability.
RFQ:
Q:Are you a factory or trading company?
A:We are a factory with 10+ years experience in led display industry. We can offer better price than trading Company.
Q: Where is your factory located? How can I visit there?
A: Our factory address is: B block, NO.56 Heng dong ling Industrial Zone, Shenzhen, China. We can pick you up from airport or your hotel for visiting.
Q: How to get the price list?
A: Sorry that we don't have price list because each project has difference requirements, and we quote according to your detailed requirements.
Q: How could I buy the products I need if there is no price in the website?
A: You can send your inquiry to us about the products you need,our sales will reply you within 24 hours to help you make the order.
Q: What is LED?
A: LED is sanded for Light Emitting Diode, a kind of semiconductor which is used to give and receive the electronic signal into infrared rays or light, using the characteristics of compound semiconductor. This is used for household appliances, remote controller, electric bulletin board, various kinds of automation appliances.
Q: What are Pixel Pitch, Pixel Density, LED QTY, and Pixel Configuration?
A: Pixel Pitch is the distance between neighboring pixels.Pixel Density is the quantity of pixels per square meter. LED QTY is the quantity of LED lamps per square. Pixel Configuration is the description of the consistence of a pixel, for instance, we use 1 red lamp, 1 green lamp, and 1 blue lamp to compose a pixel, the pixel configuration is 1R1G1B.
Product specification:
INDOOR RENTAL | ||||||||
Item | Value | |||||||
Model NO. | CDR-301 | CDR-391 | CDR-401 | CDR-481 | CDR-501 | CDR-601 | CDR-621 | CDR-101 |
Pixel Pitch | 3 | 3.91 | 4 | 4.81 | 5 | 6 | 6.25 | 10 |
Pixel Density (dots/sqm) | 111111 | 65536 | 62500 | 43264 | 40000 | 27777 | 25600 | 10000 |
LED Type | SMD2121 | SMD3528 | ||||||
Viewing Angle | H:120 V:120 | |||||||
Brightness (nits) | 800~1200 | |||||||
Refresh Rate (Hz) | 1920~3000 | |||||||
Module Size(mm) | 192*192 | 250*250 | 256*128 | 250*250 | 320*160 | 192*192 | 250*250 | 320*160 |
Cabinet Size (mm) | 576*576 | 500*500/500*1000 | 512*512 | 500*500/500*1000 | 640*640 | 576*576 | 500*500/500*1000 | 640*640 |
Cabinet Material | Die-casting aluminum / Magnalium | |||||||
Cabinet Weight | ≤ 35KG/SQM | |||||||
Power Consumption (Avg./Max. W/㎡) | 270/680 | 190/480 | 130/345 | 190/480 | 200/500 | 125/310 | 230/560 | 120/300 |
IP Grade | IP43 / IP31 | |||||||
Operating Temp/Humidity | -20℃~45℃ 10~90%RH | |||||||
Storage Temp/Humidity | -25℃~50℃ 10~90%RH | |||||||
Lifetime(hours) | ≥50000(Nomal Temp) |
Why choose us?
1. Diversified products: Varieties of models for outdoor/indoor LED display screens, and customized cabinets available, meet all requirements and win more profits for customers.
2. Quality assurance: Quality control is taken both in product design and production. As the quantity of PCB and other components have been decreased and simplified. Our engineers can concern in a small quantity of defect to solve and it will be a substantial boost of the yield rate. 100% testing before packing make sure our quality before delivery.
3. Best raw materials: High quality, good stability and reliability.
4. Competitive price: Factory price which is competitive in the market.
5. Prompt &Professional service: Any inquires will be replied within 12 hours in working days and you’ll get helpful suggestions from us.
The products we offer:
Indoor fixed and rental: P1.667,P1.923,P2,P2.5,P3,P4,P5,P6,P3.91,P,4.81 P6.25,P7.62,P10
Outdoor fixed and rental: P3,P4,P5,P6,P3.91,P,4.81 P6.25,P8,P10,P12,P16,P20
Mobile truck led display, transparent glass window led display.creative led display (ball led display, dj led display) and other customerized led display products
Our Services
Pre-producing:
1. Get complete requirements of clients.
2. To do a thorough analysis.
3. Offer a most reasonable and scientific solution.
4. Customized design.
In producing:
1. Producing progress updating for clients.
2. Provide Installation drawing for clients.
After service:
1. 2 years free maintenance.
2. 7 days a week, 24 hours a day on-line technical support for any clients.
3. Free training for customers in factory.
4. Local Installation Guidance Service.
