Specifications
Brand Name :
CIRID
Model Number :
CDR-591
Certification :
CE, RoHS,UL
Place of Origin :
Shenzhen
MOQ :
1PCS
Price :
negotiable
Supply Ability :
1000SQM PER DAY
Delivery Time :
15 WORKING DAYS
Packaging Details :
Flight case
Pixel Density (dots/sqm) :
28224
Pixel Pitch :
5.95
Brightness :
800
Refresh Rate :
2000
Module Size :
250*250
Cabinet Size (mm) :
500*1000
IP Grade :
IP31
name :
Curved LED Screen
Description

P3.91 P4.81 P5.95 P6.25 Support Curved Flexible Rental Led Display Indoor

Product features:

1. High refresh rate and high gray scale to make the picture vivid which meets the demand of high visual quality of commercial usage.
2. Neat appearance,light weight,small size and safe 5V low voltage power supply system all make the module more attractive.
3. Fast installation and front maintenance design is available, make your LED display business more proffessional and easier.
4. The main structure is made of aluminum alloy material, the product more light and strong, and excellent heat conduction characteristics.
5. Special heat-disspating channel design to ensure heat radiate rapidly and effectively.
6. Horizontal viewing angle 140 degree without black block.

RFQ:

Q: Do you have CE/ROHS certificate?
A: Yes, we have the certificate.

Q: What's the shiping method?
A: Our products could be shipped by sea, by air, and by express.

Q: Can I use my own forwarder to transport the products for me?
A: Yes, if you have your own forwarder, you can let your forwarder ship the products for you. But it is suggested that use our forwarder because we have long-term good relationship with them for good price and service.

Q: What's the Payment method?
A: T/T for bank transfer, 70% deposit before production, the balance before delivery. But paypal, west union,etc. also available.

Q: How does your factory do regarding quality control?
A: Quality is priority. Great importance to quality controlling from the very beginning to the very end. We are seeking long term relationship with our clients not once done business.

Product specification:

INDOOR RENTAL
Item Value
Model NO. CDR-301 CDR-391 CDR-401 CDR-481 CDR-501 CDR-601 CDR-621 CDR-101
Pixel Pitch 3 3.91 4 4.81 5 6 6.25 10
Pixel Density (dots/sqm) 111111 65536 62500 43264 40000 27777 25600 10000
LED Type SMD2121 SMD3528
Viewing Angle H:120 V:120
Brightness (nits) 800~1200
Refresh Rate (Hz) 1920~3000
Module Size(mm) 192*192 250*250 256*128 250*250 320*160 192*192 250*250 320*160
Cabinet Size (mm) 576*576 500*500/500*1000 512*512 500*500/500*1000 640*640 576*576 500*500/500*1000 640*640
Cabinet Material Die-casting aluminum / Magnalium
Cabinet Weight ≤ 35KG/SQM
Power Consumption (Avg./Max. W/㎡) 270/680 190/480 130/345 190/480 200/500 125/310 230/560 120/300
IP Grade IP43 / IP31
Operating Temp/Humidity -20℃~45℃ 10~90%RH
Storage Temp/Humidity -25℃~50℃ 10~90%RH
Lifetime(hours) ≥50000(Nomal Temp)

Why choose us?

1. Diversified products: Varieties of models for outdoor/indoor LED display screens, and customized cabinets available, meet all requirements and win more profits for customers.

2. Quality assurance: Quality control is taken both in product design and production. As the quantity of PCB and other components have been decreased and simplified. Our engineers can concern in a small quantity of defect to solve and it will be a substantial boost of the yield rate. 100% testing before packing make sure our quality before delivery.

3. Best raw materials: High quality, good stability and reliability.

4. Competitive price: Factory price which is competitive in the market.

5. Prompt &Professional service: Any inquires will be replied within 12 hours in working days and you’ll get helpful suggestions from us.

The products we offer:

Indoor fixed and rental: P1.667,P1.923,P2,P2.5,P3,P4,P5,P6,P3.91,P,4.81 P6.25,P7.62,P10

Outdoor fixed and rental: P3,P4,P5,P6,P3.91,P,4.81 P6.25,P8,P10,P12,P16,P20

Mobile truck led display, transparent glass window led display.creative led display (ball led display, dj led display) and other customerized led display products

Our Services

Pre-producing:
1. Get complete requirements of clients.
2. To do a thorough analysis.
3. Offer a most reasonable and scientific solution.
4. Customized design.

In producing:
1. Producing progress updating for clients.
2. Provide Installation drawing for clients.

After service:
1. 2 years free maintenance.
2. 7 days a week, 24 hours a day on-line technical support for any clients.
3. Free training for customers in factory.
4. Local Installation Guidance Service.
