Specifications
Brand Name :
CIRID
Model Number :
CDR-391
Certification :
CE, RoHS,UL
Place of Origin :
Shenzhen
MOQ :
1PCS
Price :
negotiable
Supply Ability :
1000SQM PER DAY
Delivery Time :
15 WORKING DAYS
Packaging Details :
Flight case
Model NO. :
CDR-391
LED Type :
SMD2121
Brightness :
800
Refresh Rate :
1920
Module Size :
250*250
Cabinet Material :
Die casting aluminum
Cabinet Size (mm) :
500*500
Description

Stage events Die Casting P2.97 P3.91 P4.81 Outdoor Indoor Rental Led Display

Product features:

1. High definition effect comes with uniform luminance and soft color is suitable for indoor close range viewing.
2. High refresh rate and high gray scale to make the picture vivid which meets the demand of high visual quality of commercial usage.
3. Constant current chip driving reduces the power consumption and prompts the stability, simple modular design is low cost and easy to maintain.

4. High refresh rate and high gray scale to make the picture vivid which meets the demand of high visual quality of commercial usage.
5. Constant current chip driving reduces the power consumption and prompts the stability, simple modular design is low cost and easy to maintain.
6. Neat appearance,light weight,small size and safe 5V low voltage power supply system all make the module more attractive.

RFQ:

Q:Are you a factory or trading company?
A:We are a factory with 10+ years experience in led display industry. We can offer better price than trading Company.

Q: Where is your factory located? How can I visit there?
A: Our factory address is: B block, NO.56 Heng dong ling Industrial Zone, Shenzhen, China. We can pick you up from airport or your hotel for visiting.

Q: How to get the price list?
A: Sorry that we don't have price list because each project has difference requirements, and we quote according to your detailed requirements.

Q: Can I use my own forwarder to transport the products for me?
A: Yes, if you have your own forwarder, you can let your forwarder ship the products for you. But it is suggested that use our forwarder because we have long-term good relationship with them for good price and service.

Q: What's the Payment method?
A: T/T for bank transfer, 70% deposit before production, the balance before delivery. But paypal, west union,etc. also available.

Q: How does your factory do regarding quality control?
A: Quality is priority. Great importance to quality controlling from the very beginning to the very end. We are seeking long term relationship with our clients not once done business.

Product specification:

INDOOR RENTAL
Item Value
Model NO. CDR-301 CDR-391 CDR-401 CDR-481 CDR-501 CDR-601 CDR-621 CDR-101
Pixel Pitch 3 3.91 4 4.81 5 6 6.25 10
Pixel Density (dots/sqm) 111111 65536 62500 43264 40000 27777 25600 10000
LED Type SMD2121 SMD3528
Viewing Angle H:120 V:120
Brightness (nits) 800~1200
Refresh Rate (Hz) 1920~3000
Module Size(mm) 192*192 250*250 256*128 250*250 320*160 192*192 250*250 320*160
Cabinet Size (mm) 576*576 500*500/500*1000 512*512 500*500/500*1000 640*640 576*576 500*500/500*1000 640*640
Cabinet Material Die-casting aluminum / Magnalium
Cabinet Weight ≤ 35KG/SQM
Power Consumption (Avg./Max. W/㎡) 270/680 190/480 130/345 190/480 200/500 125/310 230/560 120/300
IP Grade IP43 / IP31
Operating Temp/Humidity -20℃~45℃ 10~90%RH
Storage Temp/Humidity -25℃~50℃ 10~90%RH
Lifetime(hours) ≥50000(Nomal Temp)

The products we offer:

Indoor fixed and rental: P1.667,P1.923,P2,P2.5,P3,P4,P5,P6,P3.91,P,4.81 P6.25,P7.62,P10

Outdoor fixed and rental: P3,P4,P5,P6,P3.91,P,4.81 P6.25,P8,P10,P12,P16,P20

Mobile truck led display, transparent glass window led display.creative led display (ball led display, dj led display) and other customerized led display products

Our advantages:
1. Goods is examined before delivery, professional QC team.
2. Variety of customized products to satisfy different requestments.
3. Highest cost-effective price in the market.
4. All inquiry will be answered within 24 hours by a well-trained and experienced staffs.
5. Top quality & reasonable price & responsible after service.
6. All private information will be well protected.
7. All products undergo a strict aging test. The 72 hours aging test is conducted without die lamp, dim lamp, color difference and mosaic. The product is deliveryed only if it passes the aging test to ensure the best quality.
8. We specialize in high quality products.
9. We have professional R&D team who has professional development ability.
10. We are factory, we can offer better price than trading Company.

Our Services

Pre-producing:
1. Get complete requirements of clients.
2. To do a thorough analysis.
3. Offer a most reasonable and scientific solution.
4. Customized design.

In producing:
1. Producing progress updating for clients.
2. Provide Installation drawing for clients.

After service:
1. 2 years free maintenance.
2. 7 days a week, 24 hours a day on-line technical support for any clients.
3. Free training for customers in factory.
4. Local Installation Guidance Service.
