Outdoor Digital Comercial Advertising P8 Led Sign/Outdoor Led Display Billboard
Product Feature
1. OEM cabinet size: cabinet size is adjustable and compatible with different pixels.
2. Screen can work under very strong sunlight.
3. Outdoor standard cabinet applied with strong humidity resistance ability as well as corrossion resistance.
4. System Stable, Main controller has good compatibility, on-site system is stable.
5. Can be directly pasted on glass walls against the building for advertising and decoration, as well as been hung up for rental application as display screen.
6. 1000x500mm for each panel size, only 5 kg/10kg on weight for single panel, max thickness is limited in 54 mm, all those unique advantages make it a perfect choice for creative designing company to use on large-scale applications.
FREQUENCY ASKED QUESTIONS
Q:Are you a factory or trading company?
A:We are a factory with 10+ years experience in led display industry. We can offer better price than trading Company.
Q: Where is your factory located? How can I visit there?
A: Our factory address is: B block, NO.56 Heng dong ling Industrial Zone, Shenzhen, China. We can pick you up from airport or your hotel for visiting.
Q: How to get the price list?
A: Sorry that we don't have price list because each project has difference requirements, and we quote according to your detailed requirements.
Q: What kind of display we provide?
A: We have indoor/outdoor/led curtain/mobile LED /rental LED display/LED stage/LED DanceFloor/Irregular LED display for you choose.
Q: Except this model, are there any other models?
A: Yes, For indoor led screen we have P1.667,P1.923,P2,P2.5,P3,P4,P5,P6,P3.91,P,4.81 P6.25,P7.62,P10.
For outdoor led screen we have P3,P4,P5,P6,P3.91,P,4.81 P6.25,P8,P10,P12,P16,P20.
Q: What's the function of your led screen?
A: It supports videos, flash, WAV/MIDI, PPT, images and so on.
OUTDOOR FIXED | |||||||
Item | Value | ||||||
Model NO. | CDN-400 | CDN-500 | CDN-600 | CDN-800 | CDN-100 | CDN-100D | CDN-160D |
Pixel Pitch | 4 | 5 | 6 | 8 | 10 | 10 | 16 |
Pixel Density (dots/sqm) | 62500 | 40000 | 27777 | 15625 | 10000 | 10000 | 3906 |
LED Type | SMD1921 | SMD2727 | SMD3535 | DIP346 | |||
Viewing Angle | H:120 V:120 | H:120 V:60 | |||||
Brightness (nits) | 5000~6500 | 7000~8000 | |||||
Refresh Rate | 360~1920 | ||||||
Module Size(mm) | 256*128 | 160*160 | 192*192 | 256*128 | 320*160 | 160*160 | 256*256 |
Cabinet Size Recommended (mm) | 768*768 | 960*960 | 1024*1024 | 960*960 | 1024*1024 | ||
Cabinet Material | Steel with powder painted | ||||||
Cabinet Weight | ≈ 45KG/SQM | ||||||
Power Consumption (Avg./Max. W/㎡) | 360/900 | 400/980 | 240/600 | 280/700 | 400/980 | 300/760 | 180/550 |
IP Grade | IP65/54 | ||||||
Operating Temp/Humidity | -20℃~45℃ 10~90%RH | ||||||
Storage Temp/Humidity | -25℃~50℃ 10~90%RH | ||||||
Lifetime(hours) | ≥50000(Nomal Temp) |
The products we offer
Indoor fixed and rental: P1.667,P1.923,P2,P2.5,P3,P4,P5,P6,P3.91,P,4.81 P6.25,P7.62,P10
Outdoor fixed and rental: P3,P4,P5,P6,P3.91,P,4.81 P6.25,P8,P10,P12,P16,P20
Mobile truck led display, transparent glass window led display.creative led display (ball led display, dj led display) and other customerized led display products
Our advantages
1. Goods is examined before delivery, professional QC team.
2. Variety of customized products to satisfy different requestments.
3. Highest cost-effective price in the market.
4. All inquiry will be answered within 24 hours by a well-trained and experienced staffs.
5. Top quality & reasonable price & responsible after service.
6. All private information will be well protected.
7. All products undergo a strict aging test. The 72 hours aging test is conducted without die lamp, dim lamp, color difference and mosaic. The product is deliveryed only if it passes the aging test to ensure the best quality.
8. We specialize in high quality products.
9. We have professional R&D team who has professional development ability.
10. We are factory, we can offer better price than trading Company.
Our Services
Pre-producing:
1. Get complete requirements of clients.
2. To do a thorough analysis.
3. Offer a most reasonable and scientific solution.
4. Customized design.
In producing:
1. Producing progress updating for clients.
2. Provide Installation drawing for clients.
After service:
1. 2 years free maintenance.
2. 7 days a week, 24 hours a day on-line technical support for any clients.
3. Free training for customers in factory.
4. Local Installation Guidance Service.
