Specifications
Brand Name :
CIRID
Model Number :
CDN-500
Certification :
CE, RoHS,UL
Place of Origin :
Shenzhen
MOQ :
1PCS
Price :
negotiable
Payment Terms :
Western Union, MoneyGram, T/T
Supply Ability :
1000SQM PER DAY
Delivery Time :
15 WORKING DAYS
Packaging Details :
WOODEN BOX
Pixel Density :
40000
Pixel Pitch :
5mm
Cabinet Weight :
30KG/SQM
LED Type :
SMD
IP Grade :
IP65
Cabinet Material :
Aluminum
Description

P5/ P6/P8 Video Led Screen 3in1 Double Sides Lamp Pole Sign/Led Pole Display

Product Feature

1. OEM cabinet size: cabinet size is adjustable and compatible with different pixels.
2. Screen can work under very strong sunlight.
3. Outdoor standard cabinet applied with strong humidity resistance ability as well as corrossion resistance.

4. Both synchronous and asynchronous control system are available
5. Energy saving: low electric current, high-bright lamps, equipped with PFC switching power supply, save 30% electricity.
6. L-shape installation is available.

FREQUENCY ASKED QUESTIONS

Q:Are you a factory or trading company?
A:We are a factory with 10+ years experience in led display industry. We can offer better price than trading Company.

Q: Where is your factory located? How can I visit there?
A: Our factory address is: B block, NO.56 Heng dong ling Industrial Zone, Shenzhen, China. We can pick you up from airport or your hotel for visiting.

Q: How to get the price list?
A: Sorry that we don't have price list because each project has difference requirements, and we quote according to your detailed requirements.

Q: What is the delivery guarantee?
A: Guarantee time: 2 years. Within 2 years, if any part failed, we send new parts or repair for free, You will undertake shipping cost from your city to China and we undertake shipping cost from China to your city. After 2 years, we only charge cost price for parts and repairements, and you need to pay shipping cost go and back.

Q: What's the control system?
A: Control system could be Linsn, Nova-star, Xixun, Color light...Usually client use Linsn for fixed installation led screens, and Nova-star system for rental screens.

Q: Why is brightness important?
A: If you want images to be seen during the day, your display must compete with the Sun. The Sun emits approximately 4,000 nits of light (a nit is a measurement of light emitted from a device.) In order for an LED display to display effectively during the day, a minimum of 5,000 nits is required.

OUTDOOR FIXED
Item Value
Model NO. CDN-400 CDN-500 CDN-600 CDN-800 CDN-100 CDN-100D CDN-160D
Pixel Pitch 4 5 6 8 10 10 16
Pixel Density (dots/sqm) 62500 40000 27777 15625 10000 10000 3906
LED Type SMD1921 SMD2727 SMD3535 DIP346
Viewing Angle H:120 V:120 H:120 V:60
Brightness (nits) 5000~6500 7000~8000
Refresh Rate 360~1920
Module Size(mm) 256*128 160*160 192*192 256*128 320*160 160*160 256*256
Cabinet Size Recommended (mm) 768*768 960*960 1024*1024 960*960 1024*1024
Cabinet Material Steel with powder painted
Cabinet Weight ≈ 45KG/SQM
Power Consumption (Avg./Max. W/㎡) 360/900 400/980 240/600 280/700 400/980 300/760 180/550
IP Grade IP65/54
Operating Temp/Humidity -20℃~45℃ 10~90%RH
Storage Temp/Humidity -25℃~50℃ 10~90%RH
Lifetime(hours) ≥50000(Nomal Temp)


The products we offer

Indoor fixed and rental: P1.667,P1.923,P2,P2.5,P3,P4,P5,P6,P3.91,P,4.81 P6.25,P7.62,P10

Outdoor fixed and rental: P3,P4,P5,P6,P3.91,P,4.81 P6.25,P8,P10,P12,P16,P20

Mobile truck led display, transparent glass window led display.creative led display (ball led display, dj led display) and other customerized led display products

Our advantages
1. Goods is examined before delivery, professional QC team.
2. Variety of customized products to satisfy different requestments.
3. Highest cost-effective price in the market.
4. All inquiry will be answered within 24 hours by a well-trained and experienced staffs.
5. Top quality & reasonable price & responsible after service.
6. All private information will be well protected.
7. All products undergo a strict aging test. The 72 hours aging test is conducted without die lamp, dim lamp, color difference and mosaic. The product is deliveryed only if it passes the aging test to ensure the best quality.
8. We specialize in high quality products.
9. We have professional R&D team who has professional development ability.
10. We are factory, we can offer better price than trading Company.


Our Services

Pre-producing:
1. Get complete requirements of clients.
2. To do a thorough analysis.
3. Offer a most reasonable and scientific solution.
4. Customized design.

In producing:
1. Producing progress updating for clients.
2. Provide Installation drawing for clients.

After service:
1. 2 years free maintenance.
2. 7 days a week, 24 hours a day on-line technical support for any clients.
3. Free training for customers in factory.
4. Local Installation Guidance Service.
