P10 Full Color Ip65 Waterproof Outdoor Display Led Sign High Brightness
Product Feature
1. OEM cabinet size: cabinet size is adjustable and compatible with different pixels.
2. Screen can work under very strong sunlight.
3. Outdoor standard cabinet applied with strong humidity resistance ability as well as corrossion resistance.
4. Energy saving, less than 170W power consumption per square meter.
5. 8 Pin vibration-proof port, No screen flash affected by audio vibration.
6. Different batches can be mixed to use. Different batches, not too much visual difference. can be put around the main screen.
FREQUENCY ASKED QUESTIONS
Q:Are you a factory or trading company?
A:We are a factory with 10+ years experience in led display industry. We can offer better price than trading Company.
Q: Where is your factory located? How can I visit there?
A: Our factory address is: B block, NO.56 Heng dong ling Industrial Zone, Shenzhen, China. We can pick you up from airport or your hotel for visiting.
Q: How to get the price list?
A: Sorry that we don't have price list because each project has difference requirements, and we quote according to your detailed requirements.
Q: What is your term of delivery?
A: We accept EXW, FOB Shenzhen or door to door. You can choose the one which is the most convenient or cost effective for you.
Q: What about the production time for the mass production?
A: Honestly, it depends on the order quantity and the season you place the order. Usually it takes 10 to 30 days for production.
Q: How can i place an order?
A: Please provide the details of your requirements as clear as possible. So we can send you the offer at the first time.
1) It will use for what ?
2) Where will you install it ?
3) Full color or single color?
4) It's rental installation or fixed installation ?
For designing or further discussion, it is better to contact us with Skype, in case of any delays.
OUTDOOR FIXED | |||||||
Item | Value | ||||||
Model NO. | CDN-400 | CDN-500 | CDN-600 | CDN-800 | CDN-100 | CDN-100D | CDN-160D |
Pixel Pitch | 4 | 5 | 6 | 8 | 10 | 10 | 16 |
Pixel Density (dots/sqm) | 62500 | 40000 | 27777 | 15625 | 10000 | 10000 | 3906 |
LED Type | SMD1921 | SMD2727 | SMD3535 | DIP346 | |||
Viewing Angle | H:120 V:120 | H:120 V:60 | |||||
Brightness (nits) | 5000~6500 | 7000~8000 | |||||
Refresh Rate | 360~1920 | ||||||
Module Size(mm) | 256*128 | 160*160 | 192*192 | 256*128 | 320*160 | 160*160 | 256*256 |
Cabinet Size Recommended (mm) | 768*768 | 960*960 | 1024*1024 | 960*960 | 1024*1024 | ||
Cabinet Material | Steel with powder painted | ||||||
Cabinet Weight | ≈ 45KG/SQM | ||||||
Power Consumption (Avg./Max. W/㎡) | 360/900 | 400/980 | 240/600 | 280/700 | 400/980 | 300/760 | 180/550 |
IP Grade | IP65/54 | ||||||
Operating Temp/Humidity | -20℃~45℃ 10~90%RH | ||||||
Storage Temp/Humidity | -25℃~50℃ 10~90%RH | ||||||
Lifetime(hours) | ≥50000(Nomal Temp) |
The products we offer
Indoor fixed and rental: P1.667,P1.923,P2,P2.5,P3,P4,P5,P6,P3.91,P,4.81 P6.25,P7.62,P10
Outdoor fixed and rental: P3,P4,P5,P6,P3.91,P,4.81 P6.25,P8,P10,P12,P16,P20
Mobile truck led display, transparent glass window led display.creative led display (ball led display, dj led display) and other customerized led display products
Our advantages
1. Goods is examined before delivery, professional QC team.
2. Variety of customized products to satisfy different requestments.
3. Highest cost-effective price in the market.
4. All inquiry will be answered within 24 hours by a well-trained and experienced staffs.
5. Top quality & reasonable price & responsible after service.
6. All private information will be well protected.
7. All products undergo a strict aging test. The 72 hours aging test is conducted without die lamp, dim lamp, color difference and mosaic. The product is deliveryed only if it passes the aging test to ensure the best quality.
8. We specialize in high quality products.
9. We have professional R&D team who has professional development ability.
10. We are factory, we can offer better price than trading Company.
Our Services
Pre-producing:
1. Get complete requirements of clients.
2. To do a thorough analysis.
3. Offer a most reasonable and scientific solution.
4. Customized design.
In producing:
1. Producing progress updating for clients.
2. Provide Installation drawing for clients.
After service:
1. 2 years free maintenance.
2. 7 days a week, 24 hours a day on-line technical support for any clients.
3. Free training for customers in factory.
4. Local Installation Guidance Service.
