5000 CD/Sqm RGB SMD1921 Outdoor Advertising Led Display
5000 CD/Sqm RGB SMD1921 Outdoor Advertising Led Display
5000 CD/Sqm RGB SMD1921 Outdoor Advertising Led Display
5000 CD/Sqm RGB SMD1921 Outdoor Advertising Led Display
5000 CD/Sqm RGB SMD1921 Outdoor Advertising Led Display
5000 CD/Sqm RGB SMD1921 Outdoor Advertising Led Display
5000 CD/Sqm RGB SMD1921 Outdoor Advertising Led Display
5000 CD/Sqm RGB SMD1921 Outdoor Advertising Led Display
Specifications
Brand Name :
XGC
Model Number :
P3.91
Certification :
CE ,FCC, ROSH CCC
Place of Origin :
Shenzhen,China
MOQ :
1PCS/㎡
Price :
USD660--USD900 /pcs
Payment Terms :
T/T、, Western Union、L/C、, D/A、, D/P, MoneyGram
Supply Ability :
5000㎡ per month.
Delivery Time :
7-15 days
Packaging Details :
Plywood case、flight case
Product name :
P3.91 500*500 rental LED panel outdoor
Screen dimension :
16X9m,5X3m,4X3m Or Customized
Tube chip color :
Black LED lamp,SMD1921/1919
Display function :
DVI,HDMI,SDI,VGA,etc.
Application :
Concert, theater, shopping mall, airport,etc
Warranty :
2~3Years
Brightness :
5000CD/sqm
Life span :
11years
Description

P3.91 LED video wall screen for advertising outdoor stage backdrop display

Product Description:

1. High refresh rate can be reached 3840HZ. With the best quality IC ICN2053/MBI5153, it can show you the perfect visual effect.

2. No need to disassemble the whole screen for maintenance. Each components can be detached individually for that purpose.

3. The Die casting aluminum cabinet makes the single cabinet as light ONLY 7KG.

4. Specially designed masks can make the horizontal viewing angle up to 140 degrees.

5. The aluminum structure requires no fan. Combined with the noiseless power supply, the cabinet is totally silent.

6. Combined with the brightness auto-adjusting technology and PFC power supply, low current can save energy over 35%, it means to save 35% money.

Technical Parameter for P3.91 OUTDOOR RENTAL LED DISPLAY
Module Specifications
1 Pixel Pitch 3.91mm

2 Led Type SMD1921/1919
3 Pixel configuration 1R1G1B
4 Module Size 250x250mm
5 Module Resolution 64x64pixels
6 LED Chip Epistar
7 LED brand Hongsheng/Forest/ Kinglight/Nationstar
Cabinet Specification
1 Cabinet Size 500x500mm
2 Cabinet Resolution 128x128 pixels
3 Module Qty. 2x2pcs
4 Power Supply 5V40A 200W/ 5V60A 300W
6 Cabinet Materials die casting aluminum
7 Power flight socket

1set
8 Signal flight socket 1 set
Screen Parameters
1 Pixel density 65536dots/㎡
2 Screen Resolution according to screen size
3 Cabinet Qty. according to screen size
4 Brightness ≥5000 CD/sqm
5 Refresh rate ≥1920Hz/s
6 Scanning Mode 1/16 scan
7 Viewing Angle H:140°;V:140°
8 Viewing Distance ≥4m
9 Gray Level 16 Bit
10 Power Input AC110~240V
11 Power Comsuption Max: 700W/㎡ Average:240W/㎡
12 MTBF--hours >10,000 hours
13 Life--hours ≥100,000 hours
14 IP Grade IP65
15 Operating Temperature -35℃~ 65℃
16 Storage Humidity 10℃~90℃RH
17 Control Syetem Colorlight/Nova/Linsn
18 Operating System Windows98/me/2000 /NT/XP
19 Power Supply 5V40A 200W/5V60A 300W
20 Maintance Access Back service/Front service
21 video processor Colorlight/Novastar/Linsn/VDWALL/RGBLINK
22 Control mode computer /USB/WIFI/4G

HS code: 8528591090

5000 CD/Sqm RGB SMD1921 Outdoor Advertising Led Display

5000 CD/Sqm RGB SMD1921 Outdoor Advertising Led Display

Regular flight case package(plywood also available,price will be cheaper)

5000 CD/Sqm RGB SMD1921 Outdoor Advertising Led Display

FAQ

Q1: What's the warranty of your LED Display Screen ?
A1: We have a 3-year warranty for our led display screen, and 100,000 hours life span of the led lamps.

Q2: What about your pre-sale service and post-sale service?
A2: For pre-sale service: We have a professional sales team and a 12 years technical team who are willing to answer your question 24/12. We can offer a whole complete solution for your project!

For post-sale service: We can instruct you how to use, adjust the screens, and change the boken modules with spare parts.

Also, we can send engineers to your country to solve problems. Mostly, our led display will not have big problems within warranty time!

Q3: Whats your payment term? How long it takes to delivery?

A3: We accept T/T and L/C, For both T/T and L/C, At least 30% deposit in advance, and the rest 70% before delivery.

Our average Production time is 16 days after receiving the deposit.

Q4: What's the control system?
A4: For synchronization control: We use Nova, Linsn Or Colorlight control system.

For asynchronous control: We use Onbon, or Xixun control system.

Q5: How can you ensure the led display product quality?

A5: We have 48 hours aging test and 72 hours whole screen consistency test to ensure the quality.

If any quality failures within warranty time, we will refund you on alibaba.

Application:

1, Stage led screen: easy to hanging install and fast assembly for the background video panel ,suitable to stage setting .

2, Conference & Board Rooms led screen : install in Conference & Board Rooms for meeting or stage background.

3. Stadiums & Gymnasiums led screen : install in the Stadiums & Gymnasiums to live sports event, as video wall panel

4. Meeting room & Auditoriums led screen : install with a portable section aluminum structure ,as a mobile led screen .

5. Banquet led screen: install in the banquet hall for music video or events video panel as setting.

6. Airport led screen : install in airport for festival advertisement or special video display .

Shipping Information:

  • FOB Port:Shenzhen
  • Lead Time:7 - 15 days
  • HTS Code:8528.59.10 90
  • Dimensions per Unit:120 × 70 × 70 Centimeters
  • Weight per Unit:180 Kilograms
  • Units per Export Carton:2.5
  • Export Carton Dimensions L/W/H:120 × 70 × 70 Centimeters
  • Export Carton Weight:180 Kilograms

Main Export Markets:

  • North America
  • Mid East/Africa
  • Western Europe
  • Asia
  • Australasia
  • Central/South America
  • Eastern Europe

Any third-party trademarks or images shown here are for reference purposes only. We are not authorized to sell any items bearing such trademarks.

Payment Details:

  • Payment Method:Telegraphic Transfer (TT,T/T),etc.

Product Certifications

  • Certificate Standard:EMC View verified certificate
  • Certificate Number:TMC160628003-E
  • Issue Date:04-Jul-2014
  • Issued By:TMC Testing Services(Shenzhen) Co.,Ltd
  • Expiry Date:04-Jul-2025
  • Scope/Range:Security
  • Certificate Standard:FCC View verified certificate
  • Certificate Number:TMC160628004-E
  • Issue Date:04-Jul-2016
  • Issued By:TMC Testing Services(Shenzhen) Co.,Ltd
  • Expiry Date:04-Jul-2025
  • Scope/Range:Environmental protection
  • Certificate Standard:ROHS View verified certificate
  • Certificate Number:TMC160628003-C
  • Issue Date:04-Jul-2016
  • Issued By:TMC Testing Services(Shenzhen) Co.,Ltd
  • Expiry Date:04-Jul-2025
  • Scope/Range:Environmental protection

Primary Competitive Advantages:

  • Brand-name Parts
  • Origin
  • Distributorships Offered
  • Experienced Staff
  • Green Product
  • Guarantee/Warranty
  • International Approvals
  • Military Specifications
  • Packaging
  • Price
  • Product Features
  • Product Performance
  • Prompt Delivery
  • Quality Approvals
  • Reputation
  • Service
  • Small Orders Accepted
