Triangle SMD3535 P8 Outdoor Digital Advertising Screens
Triangle SMD3535 P8 Outdoor Digital Advertising Screens
Triangle SMD3535 P8 Outdoor Digital Advertising Screens
Triangle SMD3535 P8 Outdoor Digital Advertising Screens
Triangle SMD3535 P8 Outdoor Digital Advertising Screens
Triangle SMD3535 P8 Outdoor Digital Advertising Screens
Specifications
Brand Name :
XGC
Model Number :
P8
Certification :
CE ,FCC, ROSH CCC
Place of Origin :
Shenzhen,China
MOQ :
1PCS/ 1 ㎡
Price :
USD470--USD600 /㎡
Payment Terms :
T/T、, Western Union、L/C、, D/A、, D/P, MoneyGram
Supply Ability :
5000㎡ per month.
Delivery Time :
7-15 days
Packaging Details :
Plywood case、flight case
Product name :
P8 Right Angle LED Screen
Screen dimension :
960*960mm/1024*1024mm,or customized
Application :
Real estate, bank, securities building, airport，etc
Display function :
Video,picture,Outdoor,text,graphics
Warranty :
2 Years,3~5 Years
Module size :
320*160mm/256*128mm
LED chip :
Epistar,Full Color SMD3535
Power supply :
110~220V
Refresh rate :
1920Hz,1920/3840
Description

Energy saving LED triangle display Outdoor SMD LED display P8 digital advertising right angle LED screen

Features:

1. Common cathode directly improves the color decaying(brightness, gamut,
color temperature) of the common anode during the continuous temperature rise stage,
and maintains color consistency at extreme temperatures.
2. Common cathode can improve the active power, and the low voltage(2.8V+3.8V)
is used in the light bead power supply to reduce the useless power of the
LED display screen in use, thus achieving energy saving of 20%-30%.
3. Stability long life time-------Low consumption of electricity to
increase the lifetime of LEDs.
4. Energy efficient--------average 150W per sqm, while traditional led display is over 600W per sqm

Technical Parameter for P8 OUTDOOR ENERGY SAVING LED DISPLAY
Module Specifications
1 Pixel Pitch 8mm

2 Led Type SMD3535
3 Pixel configuration 1R1G1B
4 Module Size 320x160mm
5 Module Resolution 40x20pixels
6 LED Chip Epistar
7 LED brand Hongsheng/Forest/ Kinglight/Nationstar/
Cabinet Specification
1 Cabinet Size 960x960mm
2 Cabinet Resolution 120x120 pixels
3 Module Qty. 3x6pcs
4 Power Supply 2.8V+3.8V
6 Cabinet Materials iron cabinet
7 Power flight socket 1set
Screen Parameters
1 Pixel density 15625dots/㎡
2 Screen Resolution according to screen size
3 Cabinet Qty. according to screen size
4 Brightness ≥5500 CD/sqm
5 Refresh rate ≥1920Hz/s
6 Scanning Mode 1/4 scan
7 Viewing Angle H:140°;V:140°
8 Viewing Distance ≥8m
9 Gray Level 16 Bit
10 Power Input AC110~240V
11 Power Comsuption Max: 500/㎡ Average:150W/㎡
12 MTBF--hours >10,000 hours
13 Life--hours ≥100,000 hours
14 IP Grade IP65/IP54
15 Operating Temperature -35℃~ 65℃
16 Storage Humidity 10℃~90℃RH
17 Control Syetem Colorlight/Nova/Linsn
18 Operating System Windows98/me/2000 /NT/XP
19 Power Supply 2.8V+3.8V
20 Maintance Access Back service/Front service
21 Control mode computer /USB/WIFI/4G

HS code: 8528591090

Triangle SMD3535 P8 Outdoor Digital Advertising Screens

Regular plywood package:

Triangle SMD3535 P8 Outdoor Digital Advertising Screens

Triangle SMD3535 P8 Outdoor Digital Advertising Screens

Common outdoor product project case:

Triangle SMD3535 P8 Outdoor Digital Advertising Screens

FAQ

Q: What is the brightness, viewing angle and wavelength of the LED?
A: Luminous Intensity is equal to the amount of luminous flux emitted into a very small solid angle at a defined angular orientation from the light source. The measurement for luminous intensity is the candela. Symbol is Iv.
Viewing Angle is the total cone angle in degrees encompassing the central, high luminous intensity portion of the LED beam from the on-axis peak to the off-axis point where the LED intensity is 50% of the on-axis intensity. This off-axis point is known as theta one-half ( 1/2). Two times 1/2 is the LEDs' full viewing angle; however, light is visible beyond the1/2 point.
Wavelength is the distance between two points of corresponding phase and is equal to waveform velocity divided by frequency. It defines what color human eyes could recognize
Q: What is dominant wavelength? Please specify the ranges of wavelength in red, green and blue color respectively.
A: Dominant wavelength is defined as the best range of wavelength showing the most natural color recognized by human eyes. Researches indicate that fixed colors with wavelength of 620-630nm (red), 520-530nm (green) and 460-470nm (blue), in fact mixed in a particular proportion, can get the pure white. That is, in display field, people use luminous materials with above wavelength to make "compounded" white more natural.In order to get a good balance white led display, we specify the led colors with wavelength within 4nm for each color
Q: Which chip vendors are you buying from?
A: It depends on the Customer's requirement. We can purchase from Japan, Korea, Europe, USA. We are using chips mainly from Taiwan
Q: What is the chip size you're using for outdoor display? How about indoor display?
A: For outdoor display, we're using 12mil chip for red, 14mil for both green and blue. Regarding indoor display, 9mil for red, 12mil for green and blue are currently adopted
Q: How much will the brightness of LED drop down after 1000hrs?
A: Based on the result of aging test, the brightness decay of green LED is around 5%-8%, while blue is around 10%-14% and red is around 5%-8%

Our Services

Pre-sale service:
1. Inquiries will be replied within 24 hours.
2. Market research and forecast for customer.
3. Provide unique and professional solutions based on customer's requirement.
4. Data sheet and samples offered.
5. Other required services such as special packing design, factory visiting and so on.
In-sale service:
1. Tracking producing procedures all the time.
2. Provide photos and videos as per customer's requirement during production.
3. Free spare parts provided.
After-sale service:

1.Lifetime free maintenance and upgrade.

2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Warranty: 24 months.
4. Free technician training.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.

6.Special service for big project, such as stadium, exhibitions, squares and so on

Standard Outdoor Sealed Iron Product Shipping Information:

  • FOB Port:Shenzhen
  • Lead Time:7 - 20 days
  • HTS Code:8528.59.10 90
  • Dimensions per Unit:132 × 105 × 115 Centimeters
  • Weight per Unit:250 Kilograms
  • Units per Export Carton:5.58

Main Export Markets:

  • Eastern Europe
  • Asia
  • Australasia
  • Central/South America
  • Mid East/Africa
  • North America
  • Western Europe

Any third-party trademarks or images shown here are for reference purposes only. We are not authorized to sell any items bearing such trademarks.

Payment Details:

  • Payment Method:Telegraphic Transfer (TT,T/T),Western Union,Paypal,Wechat,Alipay and so on.

Product Certifications

  • Certificate Standard:EMC View verified certificate
  • Certificate Number:TMC160628003-E
  • Issue Date:04-Jul-2014
  • Issued By:TMC Testing Services(Shenzhen) Co.,Ltd
  • Expiry Date:04-Jul-2025
  • Scope/Range:Security
  • Certificate Standard:FCC View verified certificate
  • Certificate Number:TMC160628004-E
  • Issue Date:04-Jul-2016
  • Issued By:TMC Testing Services(Shenzhen) Co.,Ltd
  • Expiry Date:04-Jul-2025
  • Scope/Range:Environmental protection
  • Certificate Standard:ROHS View verified certificate
  • Certificate Number:TMC160628003-C
  • Issue Date:04-Jul-2016
  • Issued By:TMC Testing Services(Shenzhen) Co.,Ltd
  • Expiry Date:04-Jul-2025
  • Scope/Range:Environmental protection

Primary Competitive Advantages:
