P3.91 Interactive Led Floor Screen
P3.91 Interactive Led Floor Screen
P3.91 Interactive Led Floor Screen
P3.91 Interactive Led Floor Screen
P3.91 Interactive Led Floor Screen
P3.91 Interactive Led Floor Screen
P3.91 Interactive Led Floor Screen
P3.91 Interactive Led Floor Screen
P3.91 Interactive Led Floor Screen
P3.91 Interactive Led Floor Screen
Specifications
Brand Name :
XGCLED
Model Number :
P3.91 LED floor display
Place of Origin :
Shen Zhen ,China
MOQ :
10 square meters
Supply Ability :
5000 square meter per month
Delivery Time :
7-20days
Packaging Details :
Cartons , wooden case , fright case
Model :
P3.91 LED floor display screen infrared sensor
Pixel pitch :
3.91mm
Module size :
250mmX250mm
Module resolution :
64X64pixels
Cabinet size :
500mmX1000mm
Cabinet resolution :
128X256pixels
Cabinet Material :
Die casting Aluminum
Scanning mode :
1/16
Viewing Angle :
H: 120°;V: 120°
Refresh Frequency :
≥1920 Hz
Power Comsuption :
Max :800W/㎡ Average : 400W/㎡
IP Grade :
IP65
Maintance Access :
Front service
Description

P3.91 Full Color Floor Led Display Infrared Sensor Cabinet 500mmX1000mm

1) Product features intriduction

  • Super brighness led lamp bead gold wire package and a grade raw material plastic packing
  • High-end LED screen special waterproof silica gel
  • PCB adopts exclusive line design
  • The signal cable and power cable adopt to the standard design
  • LED lamp bead bracket pure copper bracket , red light 12mil , blue green 13 mil .
  • The PC cover anti-slip and the bear weight is about 2T.
  • Realization of human -computer interaction experience (abbreviation : interactive effect)

Module Specification
1 Pixel Pitch 3.91mm
2 Led Type SMD1921
3 Module Size 250*250mm
4 Module Resolution 64*64 pixels
5 Driving IC 2038S
6 LED lamp Kinglight

Cabinet Specification

P3.91 Interactive Led Floor Screen
1 Cabinet Size 500*1000mm
2 Cabinet Resolution 128*256 pixels
3 Module Qty. 2X4pcs
4 Cabinet Materials Die-casting Aluminum
5 Cabinet Weight 10kg

Screen Parameters

P3.91 Interactive Led Floor Screen
1 Screen Size Custemized size
2 Screen thickness Cabinet 85mm + mop 130-170mm adjusted
3 Viewing Distance 5~60m
4 Brightness ≥2300cd/m2
5 Scanning Mode 1/16scan
6 Viewing Angle H: 120°;V: 120°
7 Cpntrol distance Less than 100m Using International Standard net cable (RJ45 ); over 100m distance ,using fiber for controlling
8 Gray Level 14-16 Bit
9 Refresh Frequency ≥1920 Hz
10 Power Input AC 100~240V, 50~60Hz
11 Power Comsuption Max: 800W/㎡ Average: 300~400W/㎡
12 MTBF--hours >10,000 hours
13 Life--hours ≥100,000 hours
14 IP Grade Front IP67 , Rear IP65
15 Operating Temperature -20℃～+60℃
16 Storage Humidity 10℃~60℃RH
17 Control Syetem Novastar
18 Operating System Windows98/2000/NT/XP
19 Power Supply G-ENERGY
20 Interactive system Laser sensor + camera
21 Maintance Access front service
22 Display function file formats AVI, MOV, MPG, DAT, VOB

2) Product usage

This technical specifation is only application to the use of XGCLED company light P3.91 floor tile sccreen

The special effect of floor tile screen in the stage performance has been fully and vividly , creating an audio-visual

feast that is magnificent and modern.

P3.91 LED floor tile screen modular luminescent lamp bead mini SMD1921three -in -one design

Which make LED floor tile screen indoor and outdoor have a good effect.

LED floor brick screen adopts constant current drive chip and input buffer chip , The XGCLED control system

can display video animation and image text information and characteristics.
