High Power 12000A Chrome Plating Rectifier With Modular Design
High Power 12000A Chrome Plating Rectifier With Modular Design
Specifications
Brand Name :
Hongchuang
Certification :
ISO9001:2008
Place of Origin :
Jiangsu, China
MOQ :
1 set
Payment Terms :
D/A, D/P, Western Union, MoneyGram, T/T, L/C
Supply Ability :
300 Unit/Units per Month
Delivery Time :
7-15days after payment
Packaging Details :
Plywood case for export
Name :
Big Power 12000A Chrome Plating Rectifier With Modular Design
Output Power :
>500W
Output Voltage :
18V
Output Current :
12000A
Input voltage :
Three phase AC220V/380V/415V/440V
Output current :
0-500A/1000A/2000A/3000A/5000A/8000A/10000A
Efficiency :
≥90%
Cooling way :
Air cooling/water cooling
Input Voltage :
380V
Application :
Nickel copper zinc chrome plating;water treatment
Description

Big Power 12000A Chrome Plating Rectifier With Modular Design

Product Description of Chrome Plating Rectifier:

The product adopts IGBT inverter soft switch rectifier technology, is mainly as finish electroplating rectifier power supply of all kinds of metal and nonmetal (like electroplating zinc, nickel, chrome and titanium etc), it can also be used as electrolytic rectifier power supply, general anodizing power supply and DC heating supply etc.


Operation mode: local/remote operation mode can be chosen
Output control mode: constant current/constant voltage output control mode can be chosen.
Rectifier mode: IGBT inverter soft switch rectifier, 5% energy-saving comparing with common switch rectifier power supply, 15-25% energy-saving comparing with thyristor rectifier
Main protection functions: deficient phase, overvoltage, under voltage, quick fuse alarm protection of AC power supply, output over current and current limiting protection, output short circuit and instantaneous overload protection, over temperature and overheat protection of IGBT power component, switch rectifier transformer, quick rectifier diode component and BUS copper bar, overheating and high pressure protection of wind machine, low block PWM trigger pulse protection.

Details of Chrome Plating Rectifier:

Item Content

Input voltage

1 phase 110V,220V;3 phase AC 380V, 480V, 415V, ±10%, 50-60Hz

Output DC current

Rated 500A~50KA

Output DC voltage

Rated 12V-48V

Protection class

Up to IP54 for water cooling, IP32 for air cooling

Efficiency

>90% @ rated output

Power factor

≥0.93 @ rated output

Ambient temp.

Max. 50°C

Cooling

Water or forced air cooling

Regulation range

Stepless at constant voltage or current 0-100%

Control precision

Voltage/current≤1%

Control mode

Constant current/voltage/power

Operation mode

Manual/remote

Manual control

Local digital panle Remote digital box

Relative humidity

15%-85%RH

PLC interface

RS485, 0-10V/4-20mA

Communication protocol

MODBUS,Profibus, Profinet

Process programming

Available

Polarity reverse

Available

Spare parts

Available

HMI

Touch panel or digital meters/buttons

Package

Plywood case for export

Production of Chrome Plating Rectifier:

High Power 12000A Chrome Plating Rectifier With Modular Design

High Power 12000A Chrome Plating Rectifier With Modular Design

High Power 12000A Chrome Plating Rectifier With Modular Design

High Power 12000A Chrome Plating Rectifier With Modular Design

Quality and Raw Materials:

1. 100% pre-tested on each item before shippment;

2. Through the QC inspection many times;

3. Strict production operation ;

4. Environmental protection material;

5. Made from A grade PP or PVDF or CPVC material.
