Specifications
Brand Name :
Lanshuo
Model Number :
LSZ-110
Certification :
CE ISO EAC
Place of Origin :
China
MOQ :
1 set
Price :
USD 6500-7500 per set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
2000 sets per year
Delivery Time :
5-7 working days
Packaging Details :
plywood case 1170*840*1250mm; 920*850*1250mm
Type :
Induction Melting Furnace
Rated Power :
110kw
Melting Capacity :
10kg 20kg 30kg 50kg 100kg 150kg copper bronze iron scraps
Input Current :
160A
Voltage :
3-phase 380v, 50/60hz
Oscillation Frequency :
1-15KHZ
Connecting Wire :
90mm2
Control Switch :
3*225A
Ground Wire :
2mm2
Cooling Water Pressure :
≥0.2MPa
Cooling Water Flow :
≥20L/Min
Description

110kw IGBT small tilting copper stainless steel induction melting furnace price

IGBT 10kg 20kg 30kg 50kg 100kg 150kg Copper Iron Scraps Smelting Tilting Induction Melting Furnace

1. Melting Capacity of LSZ series Induction Melting Furnace:

Model Power Melting Capacity
steel, stainless steel copper, gold, silver aluminum, aluminum alloy
LSZ-15 15kw 3kg 10kg 3kg
LSZ-25 25kw 5kg 20kg 5kg
LSZ-35 35kw 10kg 30kg 10kg
LSZ-45 45kw 18kg 50kg 18kg
LSZ-70 70kw 25kg 100kg 25kg
LSZ-90 90kw 40kg 120kg 40kg
LSZ-110 110kw 50kg 150kg 50kg
LSZ-160 160kw 100kg 250kg

100kg

2. Feature of Induction Melting Furnace:

(1) IGBT module imported from Siemens.

(2) Higher reliability and lower maintenance cost.
(3) 100% Duty cycle. 24-hour continuous working is allowed at maximum output power.

(4) Display of heating power, heating current and oscillation frequency.
(5) Simple to install. Installation can be done by unprofessional persons very easily.
(6) Convenient to change crucibles for different melting material.

(7) Continuously heating ability for 24 hours.

IGBT 10kg 20kg 30kg 50kg 100kg 150kg Copper Iron Scraps Smelting Tilting Induction Melting Furnace

3. Main technical parameters of LSZ series induction melting furnace:

Model Power Input current Voltage Oscillation frequency

Connecting wire

 Control switch
LSZ-15 15kw 18A 3-phase 380 V, 50/60 Hz 1-15KHz 10mm2 3*40A
LSZ-25 25kw 36A 10mm2 3*60A
LSZ-35 35kw 57A 16mm2 3*80A
LSZ-45 45kw 80A 35mm2 3*120A
LSZ-70 70kw 110A 50mm2 3*150A
LSZ-90 90kw 140A 75mm2 3*225A
LSZ-110 110kw 160A 90mm2 3*225A
LSZ-160 160kw 240A 120mm2 3*300A

IGBT 10kg 20kg 30kg 50kg 100kg 150kg Copper Iron Scraps Smelting Tilting Induction Melting Furnace
