1 Belt Loop Air Spring Shocks Double Convolutions Rubber Bellows AIRSUSTECH HF320/166-2
1 Belt Loop Air Spring Shocks Double Convolutions Rubber Bellows AIRSUSTECH HF320/166-2
1 Belt Loop Air Spring Shocks Double Convolutions Rubber Bellows AIRSUSTECH HF320/166-2
1 Belt Loop Air Spring Shocks Double Convolutions Rubber Bellows AIRSUSTECH HF320/166-2
1 Belt Loop Air Spring Shocks Double Convolutions Rubber Bellows AIRSUSTECH HF320/166-2
1 Belt Loop Air Spring Shocks Double Convolutions Rubber Bellows AIRSUSTECH HF320/166-2
1 Belt Loop Air Spring Shocks Double Convolutions Rubber Bellows AIRSUSTECH HF320/166-2
1 Belt Loop Air Spring Shocks Double Convolutions Rubber Bellows AIRSUSTECH HF320/166-2
Specifications
Brand Name :
AIRSUSTECH
Model Number :
HF320/166-2
Certification :
ISO/TS16949:2009
Place of Origin :
Guangzhou China
MOQ :
3Pieces
Payment Terms :
T/T, Western Union, Paypal or Others
Supply Ability :
1000PCS/Week
Delivery Time :
5-8 Working Days
Packaging Details :
Strong Carton Box or as Customers Requirement
Material :
Rubber + Steel
Certificate :
ISO/TS16949:2009
Warranty :
12 MONTHS
Packing :
Neutral Box Or As Customers' Request
Application :
For Industrial
Position :
Front Or Rear
OEM :
Welcome
Pressure Ability :
0.2-0.8 M PA
Model Size :
HF320/166-2
Sample :
Available
Description

1 Belt Loop Double Convolutions Rubber Bellows AIRSUSTECH HF320/166-2 Air Spring Shocks For Industrial

Specifications and Detailed Technical Parameters: HF320/166-2

HF320/166-2 Air Spring Nominal diameter is 320mm, the outer diameter is 166mm. And the number of convolutions is two. It has one piece of Girdle hoop/ belt loop. This convoluted air spring can be used in industrial, such as gluing machine, correcting machine, leather machinery, pipe thread making machine, etc.

Other Types of Air Spring/Air Bag/Air Suspension/ Air Ballons/Cylinder We have

The flange sealing forms of the air spring end and the connecting plate are: LHF type, JBF type, GF type, HF type and ZF type.

GUOMAT AIR SPRING MODEL TYPE
LHF Type Air Spring HF Type Air Spring GF Type Air Spring JBF Type Air Spring ZF Type Air Spring
LHF100/166-2 HF80/90-1 GF40/60-1 JBF75/106-2 ZF120/122-2
LHF100/166-2 HF80/142-2 GF100/140-2 JBF80/142-2 ZF159/128-2
LHF100/238-3 HF95/70-1 GF100/166-2 JBF82/142-2 JBF220/310-3
LHF150/212-2 HF100/166-2 GF100/238-3 JBF98/101-1 JBF230/120-1
LHF150/304-3 HF100/238-3 GF120/102-1 JBF100/166-2 BF230/140-2
LHF200/212-2 HF104/66-1 GF150/206-2 JBF100/238-3 BF230/218-2
LHF200/304-3 HF115/77-1 GF150/298-3 JBF105/58-1 BF230/316-3
LHF230/120-1 HF120/132-2 GF200/206-2 JBF112/86-1 BF240/100-1
LHF230/218-2 HF125/112-1 GF200/298-3 JBF120/132-2 BF240/165-2
LHF230/316-3 HF150/140-2 GF230/206-2 JBF125/112-1 BF250/255-2
LHF250/255-2 HF170/120-1 GF230/298-3 JBF125/228-2 BF250/218-2
LHF250/218-2 HF174/126-1 GF250/206-2 JBF126/168-2 BF250/316-3
LHF250/316-3 HF180/156-1 GF250/298-3 JBF132/100-1 JBF256/92-1
LHF256/92-1 HF180/152-2 GF280/206-2 JBF150/140-2 JBF256/166-2
LHF256/166-2 HF190/170-2 GF280/298-3 JBF150/212-2 JBF264/90-1
LHF280/218-2 HF190/248-3 GF300/218-2 JBF150/304-3 JBF280/218-2
LHF280/316-3 HF192/140-2 GF300/316-3 JBF156/113-1 JBF280/316-3
LHF300/218-2 HF208/90-1 GF320/120-1 JBF156/195-2 BF284/272-2
LHF300/316-3 HF230/116-1 GF320/215-2 JBF160/216-2 JBF290/105-1
LHF320/186-2 HF230/120-1 GF320/310-3 JBF160/230-2 JBF300/255-2
LHF320/240-2 HF230/140-2 GF400/215-2 JBF170/120-1 JBF300/218-2
LHF320/350-3 HF240/100-1 GF400/310-3 JBF174/126-1 JBF300/316-3
LHF340/226-2 HF240/165-2 GF440/215-2 JBF174/232-2 JBF310/160-1
LHF400/218-2 HF250/255-2 GF440/310-3 JBF180/152-2 JBF320/186-2
LHF400/316-3 HF264/90-1 GF500/220-2 JBF180/156-1 JBF320/240-2
LHF440/218-2 HF290/105-1 GF500/320-3 JBF190/170-2 JBF320/350-3
LHF440/316-3 HF300/255-2 GF500/420-4 JBF190/248-3

JBF340/226-2
LHF500/220-2 HF310/160-1 GF580/262-2 JBF192/140-2
LHF500/320-3 HF320/203-2 GF580/384-3 JBF200/212-2
LHF580/262-2 JBF200/304-3
LHF580/384-3 JBF208/90-1

The related picture of HF300166-2

1 Belt Loop Air Spring Shocks Double Convolutions Rubber Bellows AIRSUSTECH HF320/166-2

1 Belt Loop Air Spring Shocks Double Convolutions Rubber Bellows AIRSUSTECH HF320/166-2

This air spring can be used in vibration damping equipment. With its advantages of high frequency vibration isolation, sound insulation and low natural vibration frequency, it can better achieve vibration isolation and ensure the safety and stability of the base and control system of the vibration equipment. In addition, when transporting missiles and controlling launchers, it can also be used as a shock-absorbing base to protect the device from damage. Last but not least, use the rubber air spring as a support tool to take advantage of its light weight and ease of operation to facilitate maintenance of field vehicles and equipment, etc.
