2 Convoluted G3/4 Bodymaker Air Spring Shocks Weforma WBE 400- E1
2 Convoluted G3/4 Bodymaker Air Spring Shocks Weforma WBE 400- E1
2 Convoluted G3/4 Bodymaker Air Spring Shocks Weforma WBE 400- E1
2 Convoluted G3/4 Bodymaker Air Spring Shocks Weforma WBE 400- E1
2 Convoluted G3/4 Bodymaker Air Spring Shocks Weforma WBE 400- E1
2 Convoluted G3/4 Bodymaker Air Spring Shocks Weforma WBE 400- E1
2 Convoluted G3/4 Bodymaker Air Spring Shocks Weforma WBE 400- E1
2 Convoluted G3/4 Bodymaker Air Spring Shocks Weforma WBE 400- E1
Specifications
Brand Name :
AIRSUSTECH
Model Number :
2B6910-3/4
Certification :
ISO/TS16949:2009
Place of Origin :
Guangzhou China
MOQ :
3Pieces
Payment Terms :
T/T, Western Union, Paypal or Others
Supply Ability :
1000PCS/Week
Delivery Time :
5-8 Working Days
Packaging Details :
Strong Carton Box or as Customers Requirement
Material :
Rubber and Iron
Quality Assurance :
One Year
Packing :
Neutral Box Or As Customers' Request
Size :
24×24×24 cm
Condition :
100% Brand-New
Type :
Double Convoluted Air Spring
Port Size :
G3/4
Sample :
Available
OEM No. :
Weforma WBE 400- E1
Description

Weforma WBE 400- E1 Double Convoluted G3/4 Bodymaker Air Spring Shocks

Cross Reference

Weforma WBE 400- E1/ WBE 400 E1/ WBE400E1 convoluted air spring

Norgren PM/31092/ PM31092/ PM 31092 air spring

ContiTech FD 200-19/ FD200-19/ FD 200 19/ FD200 19/ FD20019/ 2682 045000/ 2682045000 air spring shocks

Festo EB-250-185/ EB 250 185/ EB250185 shock absorber

Festo 36 493/ 36493 air actuator

2B6910-3/4 Specifications and Tecnical Parameters

Threaded Holes

2pcs×M8×1.25 on top and bottom cover

Port size

G3/4 offset; 38mm between the air inlet and the screw center

Cover plate Dia

160mm

Height

75mm to 260mm

Rubber bellow

224mm

Max. rubber bellows

251mm

Bumper block

Without

Girdle hoop/Girdle ring

one piece

Medium

Compressed Air

Operation

Single acting

Operating pressure

0 ... 8 bar

Operating temperature

-30 ... 50 °C


2B6910-3/4 can be used in bodymaker

A machine in a can making plant called a bodymaker.

Air springs can be used to provide power and kinetic energy in bodymaker. The balance force can be provided to support the upper platen on the can machine, so that the mechanical drive only needs to perform metal forming work without lifting the platen.

Other Weforma air springs replacement we could offer

WBE 70

WBE 70-E1 G1/4 M6

WBE 100

WBE 100-E1 G1/8 2×M8

WBE 140

WBE 140-E1 G3/8 M6

WBE 150

WBE 150-E1 G1/4 2×M8

WBE 200

WBE 200-E1 G1/4 2×M8

WBE 210

WBE 210-E1 G1/2 M8

WBE 300

WBE 300-E1 G3/4 2×M8
WBE 300-E2 G1/4 2×M8

WBE 310

WBE 310-E1 G3/4 2×M8
WBE 310-E2 G1/4 2×M8
WBE 320

WBE 320-E1 G3/4 2×M8
WBE 320-E2 G1/4 2×M8

WBE 400

WBE 400-E1 G3/4 2×M8
WBE 400-E2 G1/4 2×M8

WBE 410

WBE 410-E1 G1/4 2×M8

WBE 500

WBE 500-E1 G1 2×M8
WBE 500-E2 G1/4 2×M8

WBE 510

WBE 510-E1 G1/4 2×M8

WBE 530

WBE 530-E1 G1/4 2×M8
WBE 530-E2 G3/4 2×M8

WBE 540

WBE 540-E1 G1/4 2×M8

WBE 600

WBE 600-E1 G1 4×M8

WBE 600-E2 G1/4 4×M8

WBE 610

WBE 610-E2 G1/4 4×M8

WBE 700

WBE 700-E1 G1 4×M8
WBE 700-E2 G1/4 4×M8

WBE 730 4×M12

WBE 750 4×M12

The picture of 2B6910-3/4

2 Convoluted G3/4 Bodymaker Air Spring Shocks Weforma WBE 400- E1

2 Convoluted G3/4 Bodymaker Air Spring Shocks Weforma WBE 400- E1

ContiTech
