Specifications
Supply Ability :
1000pcs/week
Payment Terms :
T/T, Western Union,Paypal or Others
Place of Origin :
Guangzhou, China
Brand Name :
AIRSUSTECH
Certification :
ISO/TS16949:2009
MOQ :
3 pieces
Packaging Details :
Strong Carton Box or as Customers Requirement
Delivery Time :
3-8 Working Days
Model Number :
2B6910
Car Make :
All
Brand :
Guomat or Neutral
Damping Force Direction :
Bidirectional
N.W. :
3.5 Kg
Warranty :
One Year
Pressure Ability :
0.2-0.8 M PA
Air Inlet :
1/4 NPT
Top Plate Hole/Stud :
3/8-16unc
Bottom Plate Hole/Stud :
3/8-16unc
Top Plate Dia :
160 mm
Bottom Plate Dia :
160 mm
Trademark :
Neutral
Transport Package :
Cartons
Specification :
24*24*24 cm
Origin :
China
HS Code :
8708809000
Port :
Huangpu, China
Part :
Air Spring
Position :
Front and Rear
Type :
Gas-Filled
Spring Type :
Air Spring
Spring Material :
Rubber
Structure :
Double Cylinder
Description

160mm Double Convoluted Air Spring W01-358-6910 Contitech Air Spring FD200-19



Specifications and Technical Data of 2B6910

Compressed Height: 3.12 / 79mm
Top Cover Plate Diameter: 6.31 inches / 160mm
Bottom Cover Plate Diameter: 6.31 inches / 160mm
Screw Center Distance : 89 mm
Distance Gas Hole Between Nut 44.5 mm
Top Cover Plate Screw (Nut) Tooth : 2pcsX 3/8-16UNC
Bottom Cover Plate Screw (Nut) Tooth : 2pcsX 3/8-16UNC
Rubber Bellows MAX Diameter: 251 mm
Rubber Bellows Natural Diameter 224 mm
The Working Stroke : MAX 260 mm to MIN 75 mm
Gas Hole / Air inlet : 1/4 NPTF
Firestone Bellows Number:20
Goodyear Part Number:2B9-201/ 2B9201 / 2B9 201
Goodyear Bellows Number:578-92-3-202 / 578923202 / 578 92 3 202
OEM Original Equipment Manufacturer:

Reference OEM
GUOMAT NO. 2B6910
Firestone W01-358-6910 / W013586910/ W01 358 6910
Contitech FD 200-19 310 / FD 200 19 310 / FD 20019 310
Goodyear 2B9-201 / 2B9 201 / 2B9201
Taurus KF218-6902
Granning 4848
Hendrickson S2630
R&STruck 1027505
Ridewell 1003586902C
Suspensions 2000-42
Watson&Chalin AS-0002


The composition of convoluted air springs

Upper Steel Plate: upper cover plate is bearing pressure and seal air inside
Waist ring: Stable part skins to prevent deformation
The connotation of screw hole: fixed as the installation of air spring in car or equipment
Gas-Filled hole / Air Inlet: By filling air porosity for inflatable air spring
Flexible bellows: The main part, can lock the air and flexible activities up and down
Rubber Bumper (Optional): Prevent the air spring up and down on the plate and base plate collision, You can choose to have also can not
The connotation of screw hole: fixed as the installation of air spring in car or equipment
Lower steel Plate: Lower steel Plate is bearing pressure and seal air inside
Description Assembly Order No.
Blind nuts, 1/4 NPT W01-358-6910
Blind nuts, 1/4 NPT, bumper W01-358-6911
Blind nuts, 3/4 NPT W01-358-6900
Blind nuts, 3/4 NPT, bumper W01-358-6901
Countersunk steel bead rings,
13/4 bolts, nuts, washers W01-358-6923
Rubber bellows only W01-358-0138

How to Calculation For Pneumatics, Such as

• Mass To Be Lifted 2000 M (Kg)
• Desired Stroke 190 S Min (Mm)
• Number Of Air Springs 4 N
• Minimum Installation Height 190 H Min (Mm)
• Minimum Installation Diameter 500 D (Mm)
• Air Pressure 6 P (Bar)


The drawing and data of GUOMAT 2B6910 air spring:


160mm Double Convoluted Air Spring W01-358-6910 Contitech Air Spring FD200-19
Other kinds of GUOMAT NO.
160mm Double Convoluted Air Spring W01-358-6910 Contitech Air Spring FD200-19
Details pictures of air spring 2B6910:
160mm Double Convoluted Air Spring W01-358-6910 Contitech Air Spring FD200-19
160mm Double Convoluted Air Spring W01-358-6910 Contitech Air Spring FD200-19
160mm Double Convoluted Air Spring W01-358-6910 Contitech Air Spring FD200-19
GUOMAT air spring production line:
160mm Double Convoluted Air Spring W01-358-6910 Contitech Air Spring FD200-19
GUOMAT 2018 Shanghai Frankfurt Auto Show:
160mm Double Convoluted Air Spring W01-358-6910 Contitech Air Spring FD200-19
