86600 Bellow Air Bag 245mm Air Spring Assembly Norgren
86600 Bellow Air Bag 245mm Air Spring Assembly Norgren
86600 Bellow Air Bag 245mm Air Spring Assembly Norgren
86600 Bellow Air Bag 245mm Air Spring Assembly Norgren
86600 Bellow Air Bag 245mm Air Spring Assembly Norgren
86600 Bellow Air Bag 245mm Air Spring Assembly Norgren
86600 Bellow Air Bag 245mm Air Spring Assembly Norgren
86600 Bellow Air Bag 245mm Air Spring Assembly Norgren
Specifications
Brand Name :
AIRSUSTECH
Model Number :
2B10x2
Certification :
ISO/TS16949:2009
Place of Origin :
Guangzhou, China
MOQ :
3 pieces
Payment Terms :
T/T, Western Union,Paypal or Others
Supply Ability :
1000pcs/week
Delivery Time :
3-8 Working Days
Packaging Details :
Strong Carton Box or as Customers Requirement
Warranty :
One Year
Pressure Ability :
0.2-0.8 M PA
Bumper :
Without
Air Inlet :
G1/2
Top Plate Hole/Stud :
M10
Bottom Plate Hole/Stud :
M10
Top Plate Dia :
260 mm
Bottom Plate Dia :
260 mm
Trademark :
Norgren
Transport Package :
Cartons
Specification :
33*33*22 cm
Origin :
Europe
HS Code :
8708809000
Port :
Huangpu, China
Function :
Damping
Material :
Rubber and Iron
Load Type :
Compression
Production Process :
Vulcanization and Crimping
Shape :
Cylinder
N.W. :
5.5 Kg
Description

Air Spring MODEL 20 Standard Code 86600 Max Height 245 MM

AIRSUSTECH NO .: 2B10x2 refer to 90587

AIRSUSTECH 2B10x2

AIRSUSTECH rubber bellows 10x2

Model:20
Type: F2

High Temp. code 88538

2,Pneumatic Actuator, Model:20, Type: F2, High Temp. code -88538, PCD: 160.3mm, Max OD-255mm, Max. Height-265mm, Min. Height-80mm, Stiffness: 18.4 daN/mm Connection: Bead Ring Flange connection, Make:
FIRESTONE 2. W01 095 0381.
B 271. DUNLOP FR model. Q9 bolt/... T20 86600.

AIRSUSTECH 2B10x2 OEM Cross reference:

AIRSUSTECH 2B10x2

Air Spring MODEL 20

Air SpringStandard Code 86600

Norgren: M / 31102 /

Norgren:M 31102 /

Norgren:M31102
CONTITECH FD 210-22 1/2 M10
DUNLOP FR SP 1538 (10x2)
NORGREN M/31102 (10x2)
WEFORMA WBZ-G 450
GRANNING 15807
SAMRO H 250-0021

Double capsule air spring 2B270- 225 D185

Can replace the following air bags (bladder cylinder, gas spring)

ContiTech : FD 210-22 1/2 M10

ContiTech : FD 210-22 DS G1 / 2

ContiTech : FD 210-22 DS G1 / 2 M10

ContiTech : FD 210-22 DS G1 / 2 CR

ContiTech : FD 210-22 DS CR G1 / 2

ContiTech : FD 210-22 DS / FD210-22DS / FD21022DS

ContiTech leather bags: FD 210-22 / FD210-22 / FD21022

Firestone: W01-R58--4058 / W01 R58 4058 / W01R584058

Firestone style: 10 ”x2 / 10” x2 / 10x2

Goodyear: 2B10-2350 / 2B10 2350 / 2B102350

Goodyear sac number: 578-92-3-2350 / 578 92 3 2350/5789232350

Springride: 2B10-2350 / 2B10 2350 / 2B102350

Springride bladder number: 578-92-3-2350 / 578 92 3 2350/5789232350

Dunlop France: SP1538

Dunlop UK (Pneuride): PNP 30545 01 12 / PNP305450112

Nominal diameter (inch) x number of turns: 10 "x2 / 10" x2 / 10x2.

WEFORMA: WBZ-G 450 / WBZ-G450 / WBZG450

Altay: 140586

Altai Co. No .: A2 250 / K01 / A2250 / K01 / A2250K01

Pared (new): 2B10-2350 / 2B10 2350 / 2B102350

Pared new skin bag number: 578-92-3-2350/578 92 3 2350/5789232350

Gu'an Zhen (gas spring): YS- -252- -2V / YS 252 2V / YS2522V

Specifications and Detail Technical Parameters:AIRSUSTECH 2B10x2

Nut / Blind Nut

Top Cover Plate Screw (Nut) Tooth : 4pcs X M10

Bottom Cover Plate Screw (Nut) Tooth : 4pcs X M10

Gas Hole / Air inlet / Air Fitting

Gas Hole / Air inlet : G1/2

Cover Plate

Top Cover Plate Diameter (Width): 210 mm

Bottom Cover Plate Diameter (Width): 210 mm

Material top and bottom plate:Steel

Rubber Bellows

Stroke of Rubber Bellows:70mm-240m

Bumper block / Buffer block

Without Bumper Block

Girdle Hoop / Girdle Ring

With Girdle Hoop :One Pieces of Girdle Hoop


Rubber material Standard up to 70°C natural rubber

AIRSUSTECH 2B10x2 air spring is used for China Leading PAPER MACHINE manufacturer, such as

toilet tissue paper making machine,
corrugated paper machine,
A4 copy paper machine,
Kraft paper machine,
writing paper machine,

stock preparation equipments,
cylinder mould paper machine,
fourdrinier paper machine,
paper making machine,
toilet paper machine,
printing paper machine,etc.
