88540 Air Spring H1726 Ride Rite Air Helper Springs Gas Filled
88540 Air Spring H1726 Ride Rite Air Helper Springs Gas Filled
88540 Air Spring H1726 Ride Rite Air Helper Springs Gas Filled
88540 Air Spring H1726 Ride Rite Air Helper Springs Gas Filled
88540 Air Spring H1726 Ride Rite Air Helper Springs Gas Filled
88540 Air Spring H1726 Ride Rite Air Helper Springs Gas Filled
Specifications
Brand Name :
AIRSUSTECH
Model Number :
1H210110
Certification :
ISO/TS16949:2009
Place of Origin :
Guangzhou, China
MOQ :
3 pieces
Payment Terms :
T/T, Western Union,Paypal or Others
Supply Ability :
1000pcs/week
Delivery Time :
3-8 Working Days
Packaging Details :
Strong Carton Box or as Customers Requirement
Warranty :
12 Months
Type :
Suspension Spring
Material :
Rubber+metal
Packing :
Neutral box or as customers' request
Condition :
100% Brand-new
Shock absorber type :
Gas-Filled
Application :
Air spring
Oe no. :
88540
Size :
24*24*24 CM
Color :
Black
Description

Air Spring Model 110 Standard Code 88540 Max OD 210 MM Connection F1​

AIRSUSTECH 1H210110 Cross OEM Original Equipment Manufacturer:

AIRSUSTECH Part Number:1H210110

Air Spring: MODEL 110

Air Spring:Standard Code 88540

AIRSUSTECH Part Number:1H210110 Specifications

Nut / Blind Nut

Top Cover Plate Screw (Nut) Tooth : 6 pcs X M 8 x 1.25

Screw Center Distance of Top Cover Plate : 118 mm

Bottom Cover Plate Screw (Nut) Tooth : 6 pcs X M 8 x 1.25

Screw Center Distance of Bottom Cover Plate : 118​ mm

Gas Hole / Air inlet / Air Fitting

Gas Hole / Air inlet : G1/2

Screw Center Distance Between Gas Hole and Nut : 59 mm

Cover Plate

Top Cover Plate Diameter: 131mm

Bottom Cover Plate Diameter: 131mm

Rubber Bellows

Rubber Bellows MAX Diameter: 210 mm

Rubber Bellows Natural Diameter : 180 mm

The Working Stroke : MIN 45 mm to MAX 145mm

Maximum Height : 145mm

Minimum Height :45 mm

Stroke Height : 100mm

Bumper block / Buffer block

Without Bumper Block

Girdle Hoop / Girdle Ring

With Girdle Hoop :no One Pieces of Girdle Hoop

How to improve the abrasion resistance of air spring AIRSUSTECH AIRSUSTECH 1H210110 refer to Air Spring Model 110 Standard Code 88540 rubber airbag?

Nowadays, the quality of China AIRSUSTECH AIRSUSTECH 1H210110 refer to Air Spring Model 110 Standard Code 88540 air spring is getting better and better, with a service life of several years. China AIRSUSTECH AIRSUSTECH 1H210110 refer to Air Spring Model 110 Standard Code 88540 The gap between air springs and imported air springs is getting smaller and smaller.

Proper use and maintenance are ways to extend the life of air spring AIRSUSTECH AIRSUSTECH 1H210110 refer to Air Spring Model 110 Standard Code 88540. Maintenance can extend the life of air springs. This must be based on the excellent quality of air spring rubber airbags. What are the methods in the production process? The service life of the air spring can be improved. What is the abrasion resistance of the air spring rubber bladder? In addition to the most basic work in the vulcanization process, the following points need to be paid attention to: 1. The smaller the particle size of ordinary fillers, the lower the dispersibility, surface activity and structural structure, and the worse the wear resistance. The best dosage is 90-100 parts of BR, 60-70 parts of oil-extended SBR, 55 parts of 50-SBR and IR, and 45-50 parts of NR.

88540 Air Spring H1726 Ride Rite Air Helper Springs Gas Filled88540 Air Spring H1726 Ride Rite Air Helper Springs Gas Filled88540 Air Spring H1726 Ride Rite Air Helper Springs Gas Filled
