Specifications
Brand Name :
AIRSUSTECH
Model Number :
2B6900
Certification :
ISO/TS16949, ISO9001
Place of Origin :
Guangzhou, China
MOQ :
3 pieces
Payment Terms :
T/T, Western Union,Paypal or Others
Supply Ability :
1000pcs/week
Delivery Time :
3-8 Working Days
Packaging Details :
Strong Carton Box or as Customers Requirement
Model NO. :
2B6900
Warranty :
One Year
Pressure Ability :
0.2-0.8 M PA
Air Inlet :
3/4 NPT
Top Plate Hole/Stud :
3/8-16unc
Bottom Plate Hole/Stud :
3/8-16unc
Top Plate Dia :
160 mm
Bottom Plate Dia :
160 mm
Trademark :
Neutral
Transport Package :
Cartons
Specification :
24*24*24 cm
Origin :
China
HS Code :
8708809000
Port :
Huangpu, China
Material :
Rubber and Iron
Position :
Front and Rear
OEM :
Yes
Type :
Suspension Spring
N.W. :
3.5 Kg
Description

2B9-216 Rubber Air Spring Actuator with 3/4 NPT Air Inlet Bellows 578923202 For Clothes Organizer


OEM Original Equipment Manufacturer:

BELLOW NumbersCOMPLETE Numbers
AIRSUSTECH:2B6900
AIRSUSTECH:2B200		Firestone : W01-358-6900
Firestone : W01 358 6900
Firestone : W013586900
Goodyear : 2B9-200
Goodyear :2B9 200
Goodyear : 2B9-202
Goodyear : 2B9-216		Contitech : FD 200-19 320
Contitech : FD 200 19 320
Contitech : FD200 19 320

FIRESTONE FLEX 20
FIRESTONE W01-358-0138
FIRESTONE W01 358 0138
FIRESTONE W013580138

CONTITECH FD 20019 S / 895 N
CONTITECH FD20019S / 895 N
095-0009Hendrickson : S8768/458433
GOODYEAR 2B 9-200: 578423202
578923202Triangle: 6325
Triangle: 4320
PHOENIX 2B 12R
PHOENIX 2B12R		Dayton : 3546910
PIRELLI T20 86600Leland : Sc2011
AIRKRAFT 114001Navistar : 554783C1
Dina : A812719/AZ812719
SAF Holland : 57006910
Trailers De : 133128
Brake & Wheel : M3501
Ridewell : 1003586910C
Tuthill : 1371
Watson&Chalin : AS-0001/AS-0156G


Specifications and Technical Data of 2B9-216

Goodyear part number: 2B9-216 / 2B9216 / 2B9 216
Firestone part number: W01-358-6900 / W013586900 / W01 358 6900
Compressed height: 3.12
Number of top plates: 3079
Top cover diameter: 6.31 inches / 160 mm
Number of bottom pistons: 3090
Bottom cover diameter: 6.31 inches / 160 mm
Screw center distance: 89 mm
The distance between the nuts is 44.5 mm
Top cover screw (nut) teeth: 2pcsX 3 / 8-16UNC
Bottom cover screw (nut) teeth: 2pcsX 3 / 8-16UNC
Rubber bellows MAX diameter: 251 mm
Rubber bellows natural diameter 224 mm
Working stroke: up to 260 mm to MIN 75 mm
Air vent / air inlet: 3/4 NPTF
Firestone Corrugated Tube Number: 20
Goodyear Bellows Number: 578-92-3-202 / 578923202/578 92 3 202
Number of grids: 1371
Hendrickson Trailer No.: S-8768
Hendrickson Truck Number: 45843-3
Ridewell number: 1003586910C
Triangle part number: 4320
Triangle bellows number: 6325
Watson&Chalin#:AS-0001

Description Assembly Order No.
Blind nuts, 1/4 NPT W01-358-6910
Blind nuts, 1/4 NPT, bumper W01-358-6911
Blind nuts, 3/4 NPT W01-358-6900
Blind nuts, 3/4 NPT, bumper W01-358-6901
Countersunk steel bead rings,
13/4 bolts, nuts, washers W01-358-6923
Rubber bellows only W01-358-0138

The composition of convoluted air springs

Upper Steel Plate: upper cover plate is bearing pressure and seal air inside
Waist ring: Stable part skins to prevent deformation
The connotation of screw hole: fixed as the installation of air spring in car or equipment
Gas-Filled hole / Air Inlet: By filling air porosity for inflatable air spring
Flexible bellows: The main part, can lock the air and flexible activities up and down
Rubber Bumper (Optional): Prevent the air spring up and down on the plate and base plate collision, You can choose to have also can not
The connotation of screw hole: fixed as the installation of air spring in car or equipment
Lower steel Plate: Lower steel Plate is bearing pressure and seal air inside


How to Calculation For Pneumatics, Such as

• Mass To Be Lifted 2000 M (Kg)
• Desired Stroke 190 S Min (Mm)
• Number Of Air Springs 4 N
• Minimum Installation Height 190 H Min (Mm)
• Minimum Installation Diameter 500 D (Mm)
• Air Pressure 6 P (Bar)
