Scaffold Caster Wheel With Tube Stem
Scaffold Caster Wheel With Tube Stem
Specifications
Model Number :
S-T-PU150
Place of Origin :
China
MOQ :
500pcs
Price :
negotiable
Payment Terms :
T/T,Western Union
Supply Ability :
2000pcs per day
Delivery Time :
5-7 working days
Packaging Details :
stardard export carton
name :
scaffolding caster wheels
application :
scaffolding equipment
guarantee :
one year under normal condition use
material :
polyurethane on cast iron
diameter :
6 inch
tread width :
50mm
tube inner diameter :
55mm
tube outer diameter :
60mm
tube length :
100mm
load capacity :
250kgs
bearing :
double ball bearing
surface treatment :
zinc plated
Description

scaffold caster with hollow pipe

DESCRIPTION

This scaffold caster wheel is heavy duty to handle 500 pounds

The steel body is thick and zinc plated
The stem on our caster is 55mm ID ,60mm OD and 100mm length
Caster diameter 6 inch and 8 inch ,moldon polyurethane wheel , 2 inches wide

There are ball bearings in the pivot mechanism to handle high loading.

Locks to prevent wheel pivot and locks to prevent the scaffold caster wheel from rolling

Technical parameters

Picture Item No. Wheel material Wheel diameter Wheel width Load capacity Setting height Tube stem inner diameter Tube stem outer diameter Tube stem length Bracket thickness
Scaffold Caster Wheel With Tube Stem S-T-R150 rubber 150mm 50mm 250kg 190mm 55mm 60mm 100mm 4.5
S-T-R200 rubber 200mm 50mm 300kg 230mm 55mm 60mm 100mm 4.5

Picture Item No. Wheel material Wheel diameter Wheel width Load capacity Setting height Tube stem inner diameter Tube stem outer diameter Tube stem length Bracket thickness
Scaffold Caster Wheel With Tube Stem S-T-R150 rubber 150mm 50mm 250kg 190mm 55mm 60mm 100mm 5.5
S-T-R200 rubber 200mm 50mm 300kg 230mm 55mm 60mm 100mm 5.5

Scaffold Caster Wheel With Tube StemScaffold Caster Wheel With Tube Stem
