M16 X 1.25 Forming Tap Carbide Steel Thread Milling Cutter For Aluminum Stainless Steel Machining
M16 X 1.25 Forming Tap Carbide Steel Thread Milling Cutter For Aluminum Stainless Steel Machining
M16 X 1.25 Forming Tap Carbide Steel Thread Milling Cutter For Aluminum Stainless Steel Machining
M16 X 1.25 Forming Tap Carbide Steel Thread Milling Cutter For Aluminum Stainless Steel Machining
M16 X 1.25 Forming Tap Carbide Steel Thread Milling Cutter For Aluminum Stainless Steel Machining
M16 X 1.25 Forming Tap Carbide Steel Thread Milling Cutter For Aluminum Stainless Steel Machining
M16 X 1.25 Forming Tap Carbide Steel Thread Milling Cutter For Aluminum Stainless Steel Machining
M16 X 1.25 Forming Tap Carbide Steel Thread Milling Cutter For Aluminum Stainless Steel Machining
Specifications
Brand Name :
BABOS
Model Number :
MF16*1.5100015-Carbide
Place of Origin :
China
MOQ :
50pcs
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
10,000pcs per month
Delivery Time :
6-8 weeks
Surface Treatment :
Bright Finish
Thread Pitch :
1mm
Shank Type :
Round Shank With Square End
Cooling Method :
Internal Cooling
Material :
Tungsten Carbide
Processed Materials :
Medium strength materials
Description

M16*1.25 Forming Tap Carbide Steel Thread Milling Cutter For Aluminum Stainless Steel Machining

Product Description:

The solid carbide tap offers many benefits for those working in the machining industry. Its superior hardness and durability make it an ideal choice for drilling and forming holes in tough materials. Just be sure to handle it with care to avoid any accidents or damage to the tool.

Features:

  • Product Name: Carbide Machine Tap
  • Surface Treatment: Bright Finish
  • Shank Type: Round Shank With Square End
  • Thread Pitch: 1.25mm
  • Cooling Method: Internal Cooling

This Machine Tap is a forming Tap made of tungsten carbide. It is a high quality tool designed for use in machines.

Technical Parameters:

Material Tungsten Carbide
Cooling Method Internal Cooling
Shank Type Round Shank With Square End
Surface Treatment Bright Finish
Thread Pitch 1.25mm

Applications:

This Solid Carbide Machine Tap is suitable for short through hole, blind hole threading.

Applicable materials: Aluminum, stainless steel, die steel, cast iron, alloy steel Modulated steel, tool steel, etc.

Applicable equipment: CNC machining centers, CNC machine tools, etc.




Product Specifications:

Item No. Thread Size
(mm)		 TPI
(mm)		 Overal Length
(mm)		 Thread Length
(mm)		 Shank Diameter
(mm)		 Square Length
(mm)		 Square Width
(mm)
FM8*0.75080010-Carbide M8 0.75 80 10 6 8 4.9
FM8*1090010-Carbide M8 1 90 10 6 8 4.9
FM10*0.75090012-Carbide M10 0.75 90 12 6 8 4.9
FM10*1090012-Carbide M10 1 90 12 7 8 5.5
FM10*1.25100012-Carbide M10 1.25 100 12 7 8 5.5
FM12*1100015-Carbide M12 1 100 15 9 10 7
FM12*1.25100015-Carbide M12 1.25 100 15 9 10 7
FM12*1.5100015-Carbide M12 1.5 100 15 9 10 7
MF14*1100015-Carbide M14 1 100 15 11 12 9
MF14*1.25100015-Carbide M14 1.25 100 15 11 12 9
MF14*1.5100015-Carbide M14 1.5 100 15 11 12 9
MF16*1100015-Carbide M16 1 100 15 12 12 9
MF16*1.5100015-Carbide M16 1.5 100 15 12 12 9
