Automatic Self Cleaning Water Filtration System Industrial Bag Filter Cartridge
Automatic Self Cleaning Water Filtration System Industrial Bag Filter Cartridge
Specifications
Certification :
ISO 9001; CE
Place of Origin :
China
MOQ :
5set
Price :
$540-$560/set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10000SETS/PER YEAR
Delivery Time :
20 working days
Packaging Details :
carton
D.P of Cleaning :
0.05MPa-0.07MPa
D.P Transducer :
D.P transducer / Switch
Warranty :
2 years
Filtration Precision :
50-2000um
Pressure Rating :
0.6MPa,1.0MPa, 1.6MPa,2.0MPa
Flow Range :
17-8000m3/h
Filtration Area :
4970-89530cm2
Description

304 Stainless Steel Filter Water Filtration Systems Industrial Bag Filter Cartridge Filter

  1. Filtration Process: The self-cleaning filter operates in a similar way to other filters. The fluid containing contaminants flows through the filter housing or cartridge, and the filter media traps the particles, preventing them from passing through to the outlet.

  2. Accumulation of Contaminants: As the filtration process continues, the contaminants start building up on the filter media's surface, reducing the filter's effectiveness and causing pressure drop across the filter.

  3. Cleaning Mechanism: The self-cleaning feature comes into play when the pressure drop reaches a certain threshold or when a specific time interval is reached. At this point, the filter initiates the cleaning process to restore its filtration efficiency.

  4. Cleaning Methods: There are different self-cleaning mechanisms used in various self-cleaning filter designs. Some common methods include:

    a. Backwashing: The flow direction is temporarily reversed, and a portion of the filtered fluid is used to dislodge and remove the trapped contaminants from the filter media.

    b. Mechanical Scraping: Brushes or blades may be used to physically remove the contaminants from the filter surface.

    c. Pulse Jet or Air Cleaning: Compressed air or gas is used to create a pulse that dislodges the particles, which are then flushed out.

    d. Centrifugal Action: The filter uses centrifugal force to separate contaminants from the filter media and expel them.

  5. Waste Disposal: Once the contaminants are dislodged, they are typically directed to a waste outlet, which can be a drain or a separate collection container.

Automatic Self Cleaning Water Filtration System Industrial Bag Filter Cartridge

Automatic Self Cleaning Water Filtration System Industrial Bag Filter Cartridge

Automatic Self Cleaning Water Filtration System Industrial Bag Filter Cartridge

Automatic Self Cleaning Water Filtration System Industrial Bag Filter Cartridge

Automatic Self Cleaning Water Filtration System Industrial Bag Filter Cartridge

Automatic Self Cleaning Water Filtration System Industrial Bag Filter Cartridge

Q1 : Where is your factory located?
A1 : Qingdao crowns machinery co.,ltd is located at Huangdao district ,Qingdao city, China

Q2 : Are you an integrated supplier for industrial filter machine ?
A2 : Yes, we can provide the complete solution line to customer according to customer’s requirement.

Q3 : How about the quality control in your factory?
A3 : Qingdao crowns has the SOP (Standard Operation Procedure) and all the production step must follow

up this SOP. Every machine needs at least automatic running over 72 hours and must be inspected carefully

before shipment.

Q4 : Will you offer the pre-sales service?
A4 : Yes, we have an experienced pre-sales team to support customers not only including machine, technology

also water electrical,machine layout in factory, etc.

Q5 : What about the after-service? Will you send your engineer to my country to help commission and install the

machine?
A5 : Surely, we have many experience technical engineers for oversea service, they would help you install machine

and support training to workers also.

Q6 : What is the delivery time of the machine?
A6 : Actually, the delivery time of the machines is depended on the machine options. Normally, the delivery

time of standard machine could be within 10-30 days

Q7 : What is the warranty of the machine ?
A7 : The whole machine’s warranty period is 12 months and key parts will be depended.

Q8 : Do you provide any spare parts with machine?
A8 : Yes, CROWNS will provide one set standard spare parts to customer according to different machines
