Touch Screen Water Cup Filling Machine , Drinking Water Filling Machine 15000bph

Water Cup Filling Machine Summarize:

This machine is our new product best on Italian filling technique and our many years of production experience. Three functions washing, filling, capping are composed one body, reasonable design, beautiful outsider status, easy for operation and maintenance, full automatic. It is used for filling juice, tea and milk drinking.

Water Cup Filling Machine Technical characteristics:

(1)This equipment adopts hanging bottle conveyor method, it is reliable. It does just need to change a small number of spare parts for changing different bottles.

(2)The filling part adopts Italian technique and low gravity type vacuum filling principle. Second open valve technique is adopted to ensure full filling process level.

(3)Spring type bottle clip, empty bottle automatic over 180 degrees by rail, to washing the bottle inside.

(4)Capping parts adopt Italy advanced technology, magnetic torque capping head. And the height of the cap part can be adjustable, it can be suitable for capping different height of the bottles.

Main configurations:

1. Frequency converter: Mitsubishi(Japan)
2. Proximity switch, photo switch: AUTONICS(Korea)
3. Contactor, breaker: Siemens(Germany)
4. Cylinder, magnetic valve: AirTAc
5. Liquid level sensor: China
6. Main shaft bearing: made in China
7. Seal ring: Sealtech(USA)
8. Capping bearing: SKF (Sweden)
9. All the valves, tank and pipe that contact with beverage adopts SS316

Water Cup Filling Machine Technical specs:

1. Capping heads: 10pcs
2. Filling temperature: normal
3. Filling method: Gravity type
4. Compressed air: 0.5～0.6Mpa

Power of the equipment:

1. Main motor: 7.5KW
2. Cap unscramble: 0.37KW
3. Washing pump: 0.55KW
4. Water consumption: 1.5T/h (excluding product water)
5. Dimensions: 4200×2850×2400mm
6. Weight: about 6500Kg

Spare part list
