Large Automatic Liquid Filling Machine / Reasonable Olive Oil Bottling Equipment

Encloser of light test box adopts SUS304. It can be used for inspecting the impurity in finished product with good intensity of illumination.

washing filling capping 3 in 1 machine

Summarize:

This machine is our new product best on Italian filling technique and our many years of production experience. Three functions washing, filling, capping are composed one body, reasonable design, beautiful outsider status, easy for operation and maintenance, full automatic. It is used for filling juice, tea and milk drinking.

Technical characteristics:

(1)Spring type bottle clip, empty bottle automatic over 180 degrees by rail, to washing the bottle inside.

(2)Capping parts adopt Italy advanced technology, magnetic torque capping head. And the height of the cap part can be adjustable, it can be suitable for capping different height of the bottles.

(3)The whole machine adopts Human-machine interface, PCL controller, full automatic control technology with Frequency-converter stepless speed regulating. The equipment will stop when the temperature is low, and it does automatic control the feeding and back flow. Without bottle without cap, When no bottles available, the machine will be in waiting state,and no caps will be applied. When no caps available, or the bottles are jammed, the machine will stop automatically.

(4)The whole machine equips the lubricating oil system, controlled by PLC.

Main configurations:

1. Main motor: made in China
2. Reduction gears: made in China
3. Touch screen: Siemens(Germany)
4. PLC: Mitsubishi(Japan)
5. Frequency converter: Mitsubishi(Japan)
6. Proximity switch, photo switch: AUTONICS(Korea)
7. Contactor, breaker: Siemens(Germany)
8. Cylinder, magnetic valve: AirTAc

Technical specs:

1. Capacity: 15000bph at 500ml PET bottle
2. Washing heads: 40pcs
3. Filling heads: 40pcs
4. Capping heads: 10pcs
5. Filling temperature: normal

Spare part list
