Specifications
Brand Name :
HongYu
Model Number :
HY50521603840
Certification :
CE.FCC.ROHS,CCC
Place of Origin :
China
MOQ :
5 pcs
Price :
negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
10Kpcs/month
Delivery Time :
7-15 working days
Packaging Details :
Standard export package
Size :
5.5inch
Resolution :
2160(Horizontal)*3840(Vertical)
LCM (W x H x D) (mm) :
70.26mm(H) x 133.1mm(V) x 1.0mm(T)
Active Area(mm) :
68.04(H)x120.96(V) Mm
Brightness :
1000nits
Interface Type :
40pin 2port LVDS(Adjustable)
Viewing Angle :
85/85/85/85(Typ.)(CR≥10)
Description

4k 5.5 Inch LCD TFT Resistive Touch Screen 2160x3840 MIPI Interface For 3D Printer

5.5 inch 4k lcd 2160*3840 UHD with(out) backlight with MIPI HDM-I driver board for 3D printer application

Product Description

No. Item HY
1 LCD size 5.5 inch
2 Model Name HY50521603840
3 Resolution 2160*3840(monochrome 4k LCD)
4 Active area 68.04(H)x120.96(V) mm
5 Outline Size 70.26(H)x133.1(V) x1.0(T)mm
6 Backlight Without backlight,original open cell
7 Viewing angle 85/85/85/85 (Typ.)(CR≥10)
8 Pixel Pitch 31.5*31.5 um
9 UV transmission 6~7%
10 Signal Interface 30pins MIPI
11 Environment Operating Temp.: 0~ 70 °C Storage Temp.: -10 ~ 80 °C
12 Contrast Ratio(405nm UV) 700:1
13 Aplication 3D printer

4k 5.5 Inch LCD TFT Resistive Touch Screen 2160x3840 MIPI Interface For 3D Printer

This product is our standard product, used in Android tablet computers, video players, catering equipment, CNC control and other display panels. All products can provide touch panels, PCBA solutions and complete machine solutions. Products can be made according to customer requirements Customization; if you have any questions about the product, please contaThis product is our standard product, used in Android tablet computers, video players, catering equipment, CNC control and other display panels. All products can provide touch panels, PCBA solutions and complete machine solutions. Products can be made according to customer requirements Customization; if you have any questions about the product, please contact us as soon as possible, we will serve you wholeheartedly, thank you!ct us as soon as possible, we will serve you wholeheartedly, thank you!
