POS Machine 7 LCD Display Panel , G070VW01 V.1 AUO Industrial LCD Panel
POS Machine 7 LCD Display Panel , G070VW01 V.1 AUO Industrial LCD Panel
POS Machine 7 LCD Display Panel , G070VW01 V.1 AUO Industrial LCD Panel
POS Machine 7 LCD Display Panel , G070VW01 V.1 AUO Industrial LCD Panel
POS Machine 7 LCD Display Panel , G070VW01 V.1 AUO Industrial LCD Panel
POS Machine 7 LCD Display Panel , G070VW01 V.1 AUO Industrial LCD Panel
Specifications
Brand Name :
AUO
Model Number :
G070VW01 V1
Place of Origin :
CHINA
MOQ :
10PCS
Price :
Negotiable
Payment Terms :
T/T, T/T
Supply Ability :
10PCS/DAY
Delivery Time :
1-3workingdays
Packaging Details :
45 pcs / box ;
SIZE :
7INCH
Resolution :
800*480
Brightness :
350cd/m²
Backlight :
WLED
View angle :
65/65/50/60
Model name :
G070VW01 V.1
Description

7Inch 800 ×480 350cd/m² G070VW01 V.1 Small LCD Panel (G070VW01 V1)

  • Introduction of the Original 7.0 inch industrial LCD Panel G070VW01 V1

It is New A grade panel, Wide view angle (65/65/50/60 ) ,Hight brightness 350cd/m², 7inch size ,resoultion is 800*480 ,a-si TFT LCD. It is used for automotive navigation system ,medical machine , POS machine etc industial application .

  • Specification details

Manufacturer AUO Model Namel G070VW01 V1
Screen Size 7.0INCH Screen Type LCM , a-Si TFT-LCD
Pixel Format 800(RGB)×480 [WVGA] Response Time 12/18 (Typ.)(Tr/Td)
Active Area(mm) 152.4(H)×91.44(V) mm Arrangement RGB Vertical Stripe
Bezel Area(mm) 154.4(H)×93.44(V) mm Outline(mm) 170(H)×111(V) ×8.5(D) mm
Luminance 350 cd/m² (Typ.) Treatment Antiglare, Hard coating (3H)
Viewing Angle 65/65/50/60 (CR≥10 Contrast Ratio 500:1 (Typ.) (TM)
Good View at Symmetry Work Mode NPVA, Normally Black, Transmissive
Color Depth 262K/16.7M 50% (CIE1931) Signal Type LVDS (1 ch, 6/8-bit) , 20 pins , Connector
Frame Rate 60Hz Voltage Supply 3.3V (Typ.)
Max. Ratings Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -20 ~ 70 °C Backlight WLED , 30K hours , With LED Driver
Used for Industrial application Touch screen without

Pics of the Original 7.0 inch Inustrial lcd panel G070VW01 V1

POS Machine 7 LCD Display Panel , G070VW01 V.1 AUO Industrial LCD PanelPOS Machine 7 LCD Display Panel , G070VW01 V.1 AUO Industrial LCD Panel

  • COMPANEY SERVICE :

1. Have our own stock ,kinds of panels . Fast reply RFQ immediately .

2. Ship parts from shenzhen or HK .

3. Safe transportation: Fast and safe transportation that ensures safety of your merchandise.

4. Technology advancement: Professional field applicatoin engineers (FAE) act as your exclusive technical consultant.

5. FQA :

PAYMENT : T/T ,Western union

Shipment : DHL ,FEDEX , TNT,UPS ,Sea , Air shipment etc.

Delivery time : 1-3 working days upon payment.

  • Quality Assurance of Display Panel

Products can replace free within 10 days after customers Delivered-Signed if it cannot use due to the quality problems, in the precondition of non-artificial damage. We pay for the freight only for the replacement delivery.

The warranty time is 3-12 months. Within Warranty period, products under serviceable,we will offer the repair service for free,customers afford the cost of the parts. Customers afford the freight.

Even if within the warranty period, if the following occurs, the repair service is not available.

1. The malfunction and damaged caused by incorrect use, the unauthorized repairs and alteration.

2. The damage caused by fire, flood, abnormal voltage, other natural disasters and secondary product damage.

3. The product malfunction caused by the fall and transportation failures after purchase.

4. The malfunction and damaged caused by the other barriers (man-made factors or external device).

Any problems in the after-sales service, please contact our agents or us directly.
