Specifications
Brand Name :
LG
Model Number :
LC320EUD-SDA2
Place of Origin :
CHINA
MOQ :
10PCS
Payment Terms :
T/T, T/T
Delivery Time :
1-3workingdays
Packaging Details :
Orignal package
Partno. :
LC320EUD-SDA2
SIZE :
32INCH
Resolution :
1920*1080
Brightness :
450cd/m²
Backlight :
WLED
View angle :
89/89/89/89
Price :
Negotiable
Description

120Hz+120Hz frame 32inch LCD TV PANEL LC320EUD-SDA2 Resolution1920*1080 Brightness 450cd/m²

120Hz+120Hz frame LG IPS 32inch resolution 1600*900 LCD TV PANEL LC320EUD-SDA2

Brightness is 450cd/m²; Whole view angle is89/89/89/89 ;

It is Used for LCD TV SETS; advertising outside etc

  • Specification Details :

Manufacturer LG Model Namel LC320EUD-SDA2
Screen Size 32INCH Screen Type LCM , a-Si TFT-LCD
Pixel Format 1920*1080(RGB) , WXGA Response Time 5 (Typ.)(G to G); 8 (Typ.)(MPRT) ms
Active Area(mm) 698.4 × 392.85 (H×V) Arrangement RGB Vertical Stripe
Bezel Area(mm)
705.4 × 400.0 (H×V)
Outline(mm) 735.4 × 433 (H×V×D)
Luminance 450 cd/m² (Typ.) Treatment Antiglare (Haze 10%), Hard coating (3H)
Viewing Angle 89/89/89/89Min.)(CR≥10 Contrast Ratio 1600:1 (Typ.) (TM)
Good View at Symmetry Work Mode S-IPS, Normally Black, Transmissive
Color Depth 16.7M/1.06B 72% (CIE1931) Signal Type LVDS (4 ch, 8/10-bit) , Connector , 92 pins
Frame Rate 120Hz+120Hz Voltage Supply 12.0V (Typ.)
Max. Ratings Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C Backlight WLED , 50K hours , With LED Driver
Used for TV SETS ,advertising machine Touch screen without
  • Pics of the Original 32inch IPS lcd TV panel LC320EUD-SDA2

120Hz 120Hz Frame 32 LCD TV Screen Panel 1920*1080 With Brightness 450cd/m²

  • COMPANEY SERVICE :

1. Have our own stock ,kinds of panels . Fast reply RFQ immediately .

2. Ship parts from shenzhen or HK .

3. Safe transportation: Fast and safe transportation that ensures safety of your merchandise.

4. Technology advancement: Professional field applicatoin engineers (FAE) act as your exclusive technical consultant.

5. FQA :

PAYMENT : T/T ,Western union

Shipment : DHL ,FEDEX , TNT,UPS ,Sea , Air shipment etc.

Delivery time : 1-3 working days upon payment.

  • Quality Assurance of Display Panel

Products can replace free within 10 days after customers Delivered-Signed if it cannot use due to the quality problems, in the precondition of non-artificial damage. We pay for the freight only for the replacement delivery.

The warranty time is 3-12 months. Within Warranty period, products under serviceable,we will offer the repair service for free,customers afford the cost of the parts. Customers afford the freight.

Even if within the warranty period, if the following occurs, the repair service is not available.

1. The malfunction and damaged caused by incorrect use, the unauthorized repairs and alteration.

2. The damage caused by fire, flood, abnormal voltage, other natural disasters and secondary product damage.

3. The product malfunction caused by the fall and transportation failures after purchase.

4. The malfunction and damaged caused by the other barriers (man-made factors or external device).

Any problems in the after-sales service, please contact our agents or us directly.
