Specifications
Brand Name :
LG
Model Number :
LM270WF7-SSA1
Place of Origin :
CHINA
MOQ :
10PCS
Price :
Negotiable
Payment Terms :
T/T, T/T
Delivery Time :
1-3workingdays
Packaging Details :
Orignal package
Partno. :
LM270WF7-SSA1
SIZE :
27INCH
Resolution :
1920*1080
Brightness :
250cd/m²
Backlight :
WLED
View angle :
89/89/89/89
Description

27inch 1920*1080 250cd/m² IPS Monitor LCD PANEL (LM270WF7-SSA1)

LM270WF7-SSA1 is 60Hz frame LG 27inch IPS Monitor LCD panel , the resolution is1920*1080

Brightness is 250cd/m²; wide view angle is 89/89/89/89 ;

It is Used for Desktop ,advertising machine,monitors etc

  • Specification Details :

Manufacturer LG Model Namel LM270WF7-SSA1
Screen Size 27INCH Screen Type LCM , a-Si TFT-LCD
Pixel Format 1920*1080(RGB) , WXGA Response Time 14 (Typ.)(G to G)
Active Area(mm) 597.888(H)×336.312(V) mm Arrangement RGB Vertical Stripe
Bezel Area(mm) - Outline(mm) 607.1(H)×354.1(V) ×13.7(D) mm
Luminance 250 cd/m² (Typ.) Treatment Antiglare (Haze 25%), Hard coating (3H)
Viewing Angle 89/89/89/89 Contrast Ratio 1000:1 (Typ.) (TM)
Good View at Symmetry Work Mode IPS, Normally Black, Transmissive
Color Depth 16.7M Signal Type LVDS (2 ch, 8-bit) , 30 pins , Connector
Frame Rate 60Hz Voltage Supply 5.0V (Typ.)
Max. Ratings Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C Backlight WLED; 30K hours , W/O Driver
Used for Desktop,Monitors Touch screen without
  • Pics of the Original 27inch LG IPS Monitor LCD panel LM270WF7-SSA1

LM270WF7-SSA1 LCD TV Display Panel RGB Vertical Stripe 27 Inch IPS 1920*1080

  • COMPANEY SERVICE :

1. Have our own stock ,kinds of panels . Fast reply RFQ immediately .

2. Ship parts from shenzhen or HK .

3. Safe transportation: Fast and safe transportation that ensures safety of your merchandise.

4. Technology advancement: Professional field applicatoin engineers (FAE) act as your exclusive technical consultant.

5. FQA :

PAYMENT : T/T ,Western union

Shipment : DHL ,FEDEX , TNT,UPS ,Sea , Air shipment etc.

Delivery time : 1-3 working days upon payment.

  • Quality Assurance of Display Panel

Products can replace free within 10 days after customers Delivered-Signed if it cannot use due to the quality problems, in the precondition of non-artificial damage. We pay for the freight only for the replacement delivery.

The warranty time is 3-12 months. Within Warranty period, products under serviceable,we will offer the repair service for free,customers afford the cost of the parts. Customers afford the freight.

Even if within the warranty period, if the following occurs, the repair service is not available.

1. The malfunction and damaged caused by incorrect use, the unauthorized repairs and alteration.

2. The damage caused by fire, flood, abnormal voltage, other natural disasters and secondary product damage.

3. The product malfunction caused by the fall and transportation failures after purchase.

4. The malfunction and damaged caused by the other barriers (man-made factors or external device).

Any problems in the after-sales service, please contact our agents or us directly.
