650 degree Heat Cast Nitriding Furnace Heat Die Nitriding Oven
650 degree Heat Cast Nitriding Furnace Heat Die Nitriding Oven
650 degree Heat Cast Nitriding Furnace Heat Die Nitriding Oven
650 degree Heat Cast Nitriding Furnace Heat Die Nitriding Oven
650 degree Heat Cast Nitriding Furnace Heat Die Nitriding Oven
650 degree Heat Cast Nitriding Furnace Heat Die Nitriding Oven
650 degree Heat Cast Nitriding Furnace Heat Die Nitriding Oven
650 degree Heat Cast Nitriding Furnace Heat Die Nitriding Oven
650 degree Heat Cast Nitriding Furnace Heat Die Nitriding Oven
650 degree Heat Cast Nitriding Furnace Heat Die Nitriding Oven
Specifications
Brand Name :
IRIS
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
$30000.00-$50000.00
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000sets
Delivery Time :
30days
Product name :
Nitriding Furnace Heat Cast
Application :
metal heat treatment
Max temperature :
650 degree
Voltage :
380V
Temperature control accuracy :
accurate temperature control
Vacuum control accuracy :
±10Pa
Gas control accuracy :
±0.1L
Power :
160kw
Color :
orange and blue
Warranty :
1year
Description

Nitriding Furnace Heat Cast Nitriding Furnace Heat Die Nitriding Furnace Heat For Sale

Equipment composition

1.Furnace body

(1)Furnace hood

(2)The bottom of the furnace

(3) Workbench: 1 floor in total

(4)Vacuum system: one

2. Three-in six-out step-up transformer

3. Control: three closed-loop adjustment systems, one set of main control PLC

(1)Furnace temperature closed-loop: thermocouple, temperature control instrument, chopper, IGBT form a temperature control closed-loop system to realize parameter setting and measurement value display

(2)Furnace pressure closed-loop: vacuum gauge, vacuum control instrument and vacuum pump form a vacuum control closed-loop system to realize parameter setting and measurement value display

(3)One gas control closed-loop: the gas mass flowmeter and the flow control instrument form a flow control closed-loop system to realize parameter setting and measurement value display

(4)The main control PLC: coordination and control of each action, acquisition and output of analog quantities

Parameter

Project unit 25A 50A 75A 100A
Ultimate vacuum Pa 6.67
Pressure rise rate Pa/min 0.0133
Vacuum pump pc 2x-4 2x-8 2x-8 2x-8
2x-4 2x-8 2x-8 2x-15
Furnace chamber size mm Φ760*800 Φ1060*950 Φ920*1200 Φ1100*1200
Maximum heating area cm² 1.25*104 2.5*104 3.5*104 5*104
loading capacity Kg 600 800 1000 1200
Maximum operating temperature ℃ 650 650 650 650
