24VDC Integrated Pressure Temperature Sensor For Ships
24VDC Integrated Pressure Temperature Sensor For Ships
24VDC Integrated Pressure Temperature Sensor For Ships
24VDC Integrated Pressure Temperature Sensor For Ships
Specifications
Brand Name :
Sier
Model Number :
SPT21C2
Certification :
CE,RoHS
Place of Origin :
China
MOQ :
1 piece
Payment Terms :
T/T, Western Union
Supply Ability :
5000 pieces each month
Delivery Time :
7days
Packaging Details :
Carton
Measuring Media :
Gaseous,Liquid,Water, various media compatible with S.S
Pressure Type :
Gauge pressure, Absolute pressure
Product Name :
Temperature pressure integrated transmitter
Accuracy :
0.5 % FS (0.2 % can be customized)
Installation Mode :
M20*1.5(thread),1/2 NPT,G 1/2,Others
Pressure measuring Range :
(-0.1 ~ 0 ~ 100) MPa range is optional
Description

Hirschmann Connection integrated Pressure Temperature Sensor For Ships

Description

SPT21C2 temperature pressure integrated transmitter combine isolated OEM silicon piezoresistive pressure sensitive components with Heraeus resistance and stainless steel housing

The composition of the body, the shell and the joint material are all stainless steel, the medium compatibility is good, the performance is stable and reliable, the precision is high, the service life is long;

Used for pressure and temperature measurement of various dynamic and static gas liquids. This product is widely used in water treatment, liquid level, beverages, medical equipment,

Process control and measurement in industries such as compressors.

The PCM300PT temperature-integrated transmitter has a small, lightweight, all-stainless steel seal that works in corrosive environments.

The product is easy to install and has high anti-vibration and anti-shock performance. It is widely used in process control, aviation, aerospace, automotive, Medical equipment, HVAC and other fields.

Mainly technical parameters:

Product name Temperature pressure integrated transmitter
Model HDPW500
Power supply 9 ~ 24VDC
Output single 4~20mA
Thread size M20*1.5, M14*1.5, M10*1,G1/8,G3/8,G1/2,G1/4,NPT1/4,NPT1/2 ,etc
Measuring pressure range (-0.1 ~ 0 ~ 100) MPa range is optional
Measuring temperature range (-40 ~ 0 ~ 300) °C range is optional
Measuring media

Gaseous,Liquid,Water, air,

various liquid media compatible with stainless steel;
Pressure type Gauge pressure, Absolute pressure
Accuracy 0.5 level (0.2 levels can be customized);
Overload 200%F.S
Long-term stability ≤0.2%F.S/year
Protection grade IP65

24VDC Integrated Pressure Temperature Sensor For Ships

Application

24VDC Integrated Pressure Temperature Sensor For Ships

24VDC Integrated Pressure Temperature Sensor For Ships
