IP65 Hydraulic 60MPa Industrial Pressure Transmitter
IP65 Hydraulic 60MPa Industrial Pressure Transmitter
IP65 Hydraulic 60MPa Industrial Pressure Transmitter
IP65 Hydraulic 60MPa Industrial Pressure Transmitter
Specifications
Brand Name :
Sier
Model Number :
SPT21C2
Certification :
CE,RoHS
Place of Origin :
China
MOQ :
1 piece
Payment Terms :
T/T, Western Union
Supply Ability :
5000 pieces each month
Delivery Time :
7days
Packaging Details :
Carton
Output signal :
4~20mA,1-5V(optional)
Pressure range :
-100KPa~60MPa
MOQ :
1set
Measured media :
Liquid, gas and steam
Customized :
Yes
Ambient temperature :
-40~85℃
Description

Hot Water Heater Temperature Sensor Hydraulic Oil Pressure Sensor High Temperature Pressure Transmitter

Features

1. SPT21C2 integral pressure transmitter adopts stainless steel shell structure, built in stainless steel oil filled sensor, intelligent digital circuit.

2. With precise temperature characteristic compensation, it can be used reliably and stably

3. It is suitable for gas, liquid, steam pressure measurement and pressure measurement with corrosive media.

Applicable media Liquid, Gas, Steam
Pressure range -100kPa-0, 0-0.2~-100kPa, 0-0.2~1000kpa, 0-60MPa, 70MPa
Pressure measurement Gauge Pressure, Absolute pressure, Negative pressure, Sealing pressure
Accuracy 0.2% FS, 0.5% FS
Stability ±0.25% FS/year
Zero drift 50% of full range span.
Max overload 200% of sensor range
Bandwidth / Response time 1 millisecond (Optional for analog type)
Output signals 4~20mA, 1-5V(optional)
Display LED (Optional)
Housing material 304 stainless steel
Mechanical connection M20×1.5; 1/2-18NPT, 1/4NPT, G1/4, Customize
Protection class IP65
Power supply Non-explosion: 10.5~45V DC
EEX ia:8~30 V DC
Ambient temperature -40~85℃
Process temperature -40~85℃
-40~150℃ (diaphragm type, clamp type)
Compensation temperature -10~70℃

IP65 Hydraulic 60MPa Industrial Pressure Transmitter

IP65 Hydraulic 60MPa Industrial Pressure Transmitter

FAQ

Q: Are you manufacturer or trading company?

A: We are professional pressure/level/temperature measurement manufacturer since 2017.

Q: What is the warranty of your products?

A: 12 month from shipment date, for non-man-made damages.

Q: Can we use our logo on the products? Do you provide customized products?

A: Yes, we can provide customized products per requirement. OEM/ODM is welcome

Q: What is yor MOQ?

A: We have no MOQ limits, small quantity order is acceptable.

Q: What's the transport?

A: Express such as DHL, Fedex, TNT for freight prepaid, also can use your own couier account to do the freight collect.
