10kPa SPT21C2 SS304 Industrial Temperature Sensor
10kPa SPT21C2 SS304 Industrial Temperature Sensor
10kPa SPT21C2 SS304 Industrial Temperature Sensor
10kPa SPT21C2 SS304 Industrial Temperature Sensor
Specifications
Brand Name :
Sier
Model Number :
SPT21C2
Certification :
CE, RoHS
Place of Origin :
Shaanxi, China (Mainland)
MOQ :
1 piece
Payment Terms :
T/T, Western Union
Supply Ability :
5000 pieces each month
Delivery Time :
7days
Packaging Details :
Carton
Accuracy :
±0.5%FS(typ.)
Material :
304
Response time :
30 S
Warranty :
12 month
Description

Accuracy 0.5% Electrical Connection Pressure Sensor sPT21C2 Temperature Sensor

Features

Temperature pressure sensor

Pressure range: -100kPa~0...0~10kPa...100MPa

Gas or liquid compatible with 316LSS

High reliability and stability

Output signal optional

Connection mode of connector or lead direct

Can add adjustable zero and full function as customer’s request

A variety optional of pressure interface

Parameters

Measure Range -100kPa~0.....10kPa...100MPa
Pressure Type gauge (G), absolute (A), sealed gauge (S)
Overpressure 150%FS
Accuracy 0.2%FS, 0.5%FS
Output signal 4-20mA(2-wire), 0-5V;1-5V;0.5-4.5V;0-10V(3-wire)
Supply 12-36Vdc,12~36Vdc;15~30Vdc;15~36Vdc;15~36Vdc;5Vdc
Temp.coefficient of zero ±0.02%FS/°C(typ.) ±0.03%FS/°C(max.)
Temp.coefficient of span ±0.02%FS/°C(typ.) ±0.03%FS/°C(max.)
Compensated temperature range -10~+70°C
Operating temperature range -40~+125°C
Storage temperature range -40~+125°C
Insulating resistance ≥100MΩ@100Vdc
Load resistance R≤(U-15)/0.02 (for 4/20mA) R>100kΩ(for voltage output)
Electrical interface DIN43650, option 1.5m cable connetion
Pressure interface G1/2,M20x1.5,G1/4, 1/4NPT, 1/2NPT(customer request)
Material of pressure membrane 316L stainless steel
Material of housing 1Cr18Ni9Ti stainless steel
Response time(10%~90%) ≤10ms
Shock/impact 10gRMS,(20~2000)Hz/100g,11ms
Protection IP65

Applications

• Equipment matching

• Pump and compressor, natural gas pipe network and other automatic temperature measurement and control system
• Temperature measurement for the water or oil in the fields such as petroleum, chemical industry, electricity, light textile, environmental protection etc.

FAQ

Q: Can I get some samples?

A: Yes, Sample order is available for quality check and market test. But you have to pay the express cost.

Q:How do you control your quality ?

A: Three inspection steps(of original, production, and finished goods) + good warranty service(1 year free to change a new one without any human damage factors).

Q: What's your warranty terms?

A: We offer 12 months warranty time.

Q:can you provide OEM & Customized service?

A:Yes, OEM and ODM are both available, we have the professional R&D dept which can provide professional solutions for you.
