UPS2 1000bar IP65 Digital 24VDC Water Pressure Switch
UPS2 1000bar IP65 Digital 24VDC Water Pressure Switch
Specifications
Brand Name :
Sier
Model Number :
SPK21
Certification :
CE ROHS
Place of Origin :
China
MOQ :
1piece
Supply Ability :
5000 pieces each month
Delivery Time :
7days
Packaging Details :
Carton
Pressure ranges :
-1...0~0.1...1000bar
Service life of switch :
>1million times
Pressure medium :
gas or liquid compatible with stainless steel
Overload pressure :
150%FS
Power consumption :
<3W
Description

Digital 24VDC Water Pressure Switch

Description

spk21 electronic pressure switch is pressure measurement & control product with intelligent digital display, it is combined the functions of pressure measurement, display, output and control. This product is made with entire electronic structure, and built isolated-membrane pressure sensor in its front end. Its output signal is amplified through high accuracy & low temperature swift amplifer, then is input high accuracy A/D converter, and processed by microprocessor, the processed signal controls two-way switch, to realize the pressure measurement and control for systems.


The use of spk21 electronic pressure switch is very flexible. UPS2's operation and adjustment is simple and easy, meanwhile, this product also has good reliability and safety.

Specification

pressure medium gas or liquid compatible with stainless steel
pressure ranges
-1...0~0.1...1000bar
overload pressure 150%FS
output signal 4~20mA(option)
control accuracy 0.5%FS(standard)
display range
-1999~9999
long-term stability <0.2%FS/year
display mode
 4 digit LED
supply voltage 18~32V DC
ambient temperature range -30~+80 ℃
media temperature range -40~+100 ℃
storage temperature range -20~100 ℃
service life of switch >1million times
power consumption <3W
load capacity <24V, 1.2A
process connection G1/4 or others
electrical connection aviation connector or others
material of wetted part 1Cr18Ni9Ti
relative humidity 0~80%
protection IP65

Application

UPS2 is widely used in water and electricity industry, petroleum industry, chemical industry, machinery industry etc, for the pressure measurement and control of many kinds of fluids.
