20mA Liquid Gas Pressure Transmitter OEM Gauge Pressure Transmitter
20mA Liquid Gas Pressure Transmitter OEM Gauge Pressure Transmitter
Specifications
Brand Name :
Sier
Certification :
CE,RoHS
Place of Origin :
Shaanxi, China
MOQ :
1 piece
Payment Terms :
T/T, Western Union
Supply Ability :
5000 pieces each month
Delivery Time :
7days
Packaging Details :
Carton
Product Name :
Gauge Pressure Transmitter 4-20mA
Color :
SS
Application :
liquid oil gas pressure transmitter
Warranty :
12Months
Customized support :
OEM
Description

Feathers

* Updating time of output current in 90 ms
* Improved performance, increased accuracy and greater stability
* Two years stability of 0.15%
* Parameter setting by keypad directly
* 4-20 mA output plus direct digital HART communication
* Automatic zero calibration by press-button
* Explosion proof and weather proof housing

Specification

Media to be measured
 wet soil, crude oil, corrosive liquids and gases
Pressure type absolute pressure, sealed reference pressure, vent pressure
Range 0～35MPa, 70MPa, 105MPa, 140MPa, 210MPa, 315MPa
Power supply 9-30VDC
Output signal 4-20mA, 0-5VDC, 1-5VDC, 0-10VDC, 3mV/V
Nonlinear 0.04% FS
Repeatability 0.04% FS
Accuracy 0.1% FS, 0.2% FS, 0.5% FS
Long-term stability 0.1% FS / year (typical)
Working temperature -43～85°C/125°C
Compensation temperature -25 ~ 70 ° C / 100 ° C
Response time ≤ 1 millisecond (typical)
Insulation resistance ≥500MΩ/100V
Overload pressure 200% FS (2 times full scale, special: 5 times full scale)
Destruction pressure 500% FS (5 times full scale, special 10 times full scale)
Vibration resistance about 10g/0~2000HZ
Vibration resistance about 10g/0~2000HZ
Impact resistance about 50g/1ms
Connection method Chuck seal or specifified
Wetted material
17-4PH stainless steel
Relative humidity 0～100%RH
Protection rating IP67
Electrical output lead aerospace connector, Amphenol


Electrical connection

20mA Liquid Gas Pressure Transmitter OEM Gauge Pressure Transmitter

20mA Liquid Gas Pressure Transmitter OEM Gauge Pressure Transmitter

Shipping&Payment

20mA Liquid Gas Pressure Transmitter OEM Gauge Pressure Transmitter

FAQ

Q: Are you trading company or manufacturer ?

A: We are factory.

Q: How long is your delivery time?

A: For small orders, we can deliver within 3-5 working days, for bulk orders, we usually need 15 working days or longer.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could provide the sample. But you need to pay for the cost.

Q: What certificates do you have?

A: We have CE certificate, ISO9001 Quality Control Certificate, Explosion Proof Certificate, etc.

Q: What are your main products?

A: Our main products are Pressure transmitters, flow meters, level meters, level switch, etc.
