ODM Compatible E H Deltabar S PMD75 Differential Pressure Transmitter with Performance
ODM Compatible E H Deltabar S PMD75 Differential Pressure Transmitter with Performance
ODM Compatible E H Deltabar S PMD75 Differential Pressure Transmitter with Performance
ODM Compatible E H Deltabar S PMD75 Differential Pressure Transmitter with Performance
ODM Compatible E H Deltabar S PMD75 Differential Pressure Transmitter with Performance
ODM Compatible E H Deltabar S PMD75 Differential Pressure Transmitter with Performance
ODM Compatible E H Deltabar S PMD75 Differential Pressure Transmitter with Performance
ODM Compatible E H Deltabar S PMD75 Differential Pressure Transmitter with Performance
ODM Compatible E H Deltabar S PMD75 Differential Pressure Transmitter with Performance
ODM Compatible E H Deltabar S PMD75 Differential Pressure Transmitter with Performance
Specifications
Place of Origin :
Shaanxi, China
Brand Name :
XIYI
Model Number :
E+H Deltabar S FMD76/FMD77/FMD78
Price :
$400.00 - $600.00/pieces
Warranty :
12 months
Customized support :
OEM, ODM
Product Name :
Pressure Transmitter
MOQ :
1
Description
ODM Compatible E H Deltabar S PMD75 Differential Pressure Transmitter with Performance
ODM Compatible E H Deltabar S PMD75 Differential Pressure Transmitter with Performance
ODM Compatible E H Deltabar S PMD75 Differential Pressure Transmitter with Performance

Differential pressure transmitter with monoflange diaphragm seal for level measurement
E+H Deltabar S FMD76/FMD77/FMD78 differential pressure transmitters with metal sensor, single-flange diaphragm seal, or double-flange seal, with capillary tube on the low pressure side. They are mainly used for the continuous measurement of liquid levels in the process industry. Built-in HistoROM data module for easy process and equipment parameter management. Conforms to IEC 61508 and meets SIL3 functional safety requirements. The instrument can perform the following measurements: Flow measurement of gases, vapors and liquids (volume flow or mass flow) in combination with differential pressure sensors. Level, volume and mass measurement of liquids. Instruments with diaphragm sealing system for process temperatures up to 400°C Differential pressure monitoring, e.g. for filters and pumps

Product parameters:

Measuring variables: differential pressure, pressure Measurement accuracy: 0.075% + effect of diaphragm sealing system Long-term stability:0.05%URL/year, 0.125%URL/5 years Output signal:4-20mA HART PROFIBUS PA FOUNDATION Fieldbus Process temperature: -40-400°C Ambient temperature:-40-85℃ Pressure measurement range: 100mbar-16 bar Process pressure (absolute)/maximum overpressure limit: 160 bar (2400 psi) Main wetted parts: Alloy C276, 316L, Monel, Tantalum Max. measuring distance: 160m(525ft)H20 Material of process diaphragm 316L, AllovC alloy, tantalum, gold-rhodium, PTFE Sensor: 100 mbar-16 bar Minimum calibratable range: 5 mbar (0.075psi) Anti-vacuum pressure: 50 mbar (7.25psi) Maximum range ratio: 100:1 Process connections Low pressure side: 1/4-18NPT RC1/4" High pressure side: Flange (DINASME, JIS) Housing material: 316L cast aluminum Features: Diagnostic function
ODM Compatible E H Deltabar S PMD75 Differential Pressure Transmitter with Performance
ODM Compatible E H Deltabar S PMD75 Differential Pressure Transmitter with Performance

Product advantages:

Advantage 1. Excellent repeatability and long-term stability. Advantage 2. Maximum reference measurement accuracy of 0.035%. Advantage 3. the maximum range ratio is 100:1, and a larger range ratio can be ordered through special selection ordering. Advantage 4. The highest safety level for flow and differential pressure monitoring is SIL 3, certified by TÜV SÜD and in accordance with IEC 61508. Advantage 5. High safety with functional monitoring of sensors and electronic inserts during operation. Advantage 6. the diaphragm sealing system uses the patented TempC diaphragm to minimize the measurement error caused by ambient and process temperature. Advantage 7. Histo ROM/M-DAT ensures that the electronic plug-in can be easily replaced. Advantage 8. Standardized platform for differential pressure transmitters, static pressure transmitters and pressure transmitters (Deltabar S-Deltapilot S-Cerabar S). Advantage 9. practical user interface, simple and fast commissioning. Advantage 10. equipped with a number of diagnostic functions. Advantage 11. Deltabar S FMD77 has a capillary tube mounted on the low pressure side for low installation costs.
ODM Compatible E H Deltabar S PMD75 Differential Pressure Transmitter with Performance
ODM Compatible E H Deltabar S PMD75 Differential Pressure Transmitter with Performance
ODM Compatible E H Deltabar S PMD75 Differential Pressure Transmitter with Performance
ODM Compatible E H Deltabar S PMD75 Differential Pressure Transmitter with Performance
ODM Compatible E H Deltabar S PMD75 Differential Pressure Transmitter with Performance
ODM Compatible E H Deltabar S PMD75 Differential Pressure Transmitter with Performance
Q: How long will you give me the reply?
A: we will contact you as soon as we can.
Q:What is the delivery time?
A:Our delivery time is within 3-7days after we get your payment ; for large qty mass order , the time should be confrimed again for you.
Q:Howabout your package?
A:Do not worry about the package ,we have rich experience at packing , all our package is standard exporting package.
Q:How about the payment terms?
A:You can choose T/T, Western union , or you can choose by -credit insurance.
Q:Could I visit your factory?
A: Sincerely invite you to visit our factory.
Q: Do you provide samples?
A: Yes,we have materials in stock to help you to get the samples as soon as we can.
Q:What is the MOQ?
A:1PC.
Q:Can I get a lower price if I order large quantities?
A:Yes,cheaper prices with more bigger size orders.
