Descriptions Of XD-04-MN01

Yaskawa SGMGV-20ADA61 Product information and technical parameters:
Brand: Yaskawa
Name: Rotary servo motor
Model: SGMGV-20ADA61
Sigma -V series servo motor SGMGV.
Rated output: 1.8kw.
Power supply voltage: AC200V.
Serial encoder: 20 bit Delta (standard).
Design sequence: standard.
Shaft end: straight shaft with keyway, with screw (optional).
Optional: no matching.
A variety of mechanical feed shaft drive (high speed feed).
Variety is complete (300W ~ 15kW, with hold brake).
Equipped with a high resolution serial encoder (20 bit).

Standard using IP67.
Use example:
Machine tool.
Transport machinery.
Handling machinery.
Food processing machinery.
Rating and specifications:
Rated time: continuous.
Vibration level: V15.
Insulation resistance: DC500V, 10M, or above.
Using ambient temperature: 0 ~ 40 degrees C.
Excitation mode: permanent magnet type.
Installation method: flange type.
Heat resistance grade: F.

Insulation withstand voltage: AC1500V 1 minutes (200V), AC1800V 1 minutes (400V).
Protection mode: fully enclosed self cooling type IP67 (except shaft through part).
The use of environmental humidity: 20 ~ 80% (not dew).
Connection mode: direct connection.
Rotation direction: clockwise direction (CCW) rotation at the load side under the direction of rotation

Servo motor type SGMPH (speed: 3000r/min).
Power: 0.4kw.
Power supply voltage: single phase AC200V.
Serial encoder: 13 bit relative value.
Design sequence: Waterproof standard IP67.
Shaft end: straight shaft with screw.
Optional parts: with DC90V brake.

Partial flat series: the need to install the servo motor in a small space Yaskawa SGMGV-20ADA61.
Flexible user system.
For you to build the best system to enrich the product line to support you
Products with single phase 200V, single phase 100V, three-phase 200V,
And for the absolute value encoder, a variety of motor with brake, belt speed reducer.
And then, because of its compliance with international standards, in the world can be assured that the use of.
Smooth running, there is a very seasonal rate of observation and control,
The speed fluctuation of the motor is greatly reduced, and the speed of the motor can be smoothly operatedSGM7P type (rated speed: 3000r/min) of inertia and flat servo motor in non speed reducer Yaskawa SGMGV-20ADA61.

Rated output: 0.2kw.
Power supply voltage: AC200V.
Serial encoder: 24 bit absolute value type.
Design sequence: IP65.
Shaft end: straight shaft with keyway, with screw Yaskawa SGMGV-20ADA61.
Optional parts: with brake (DC24V).
Yaskawa servo motor, also known as YASKAWA Yaskawa servo motor,
Origin of Japan, in Shenyang, China, Jiading, Shanghai also has a factory,
Is to make the position of the object, the position, the state and other output controlled,
Automatic control system capable of following an arbitrary change of an input target value (or a given value).

It is divided into AC servo motor and DC servo motor,
In the domestic semiconductor, liquid crystal manufacturing devices, electronic components packaging equipment, machine tools and general machinery has been widely used in.
As a leading enterprise for the first time Yaskawa servo drive, put forward the concept of "mechatronics",
Now has become a universal termDirect drive type servo motor SGMCV type.
Rated torque: M / 4.0N.
Servo motor diameter: diameter of 135mm.
Serial encoder: 22 bit (multi ring absolute encoder).
Design sequence: A.

Flange: reverse load side.
Optional parts: high mechanical precision (axis offset, offset 0.01mm).
Under the condition of no speed reducer, the load is directly driven.
Can be realized from low speed to high speed of the strong smooth running
(instantaneous maximum torque: 12 ~ 75N / m, maximum speed: 500 ~ 600r/min).
By using 22 bit high resolutioon encoder, the high precision can be carried out SGMGV-20ADA61.
The use of hollow structure, convenient wiring and piping.

Use example:
Semiconductor manufacturing apparatus.
Liquid crystal circuit board manufacturing device.
Various inspection andd test equipment SGMGV-20ADA61.
Electronic component packaging machine.
C information processor.
C inspection equipment.
A variety of automated machinery.
Manipulator
