Industrial Oil Gas Fired Steam Boiler For Mango Juice Sterilization Processing

General Introduction

Model: packaged steam boiler

Structure: Wet Back Fire Tube Three Pass

Rated Steam Capacity:1-25 ton/hr

Rated Steam Pressure:0.7/1.0/1.25/1.6/2.5 Mpa

Rated Steam Temperature:170/184/194/204/225 C

Application:Textile Mill,Food and Beverage,Chemical,Medicine,Light Industry,Rubber,Printing and Dyeing Plant,Paper Mill,Wood Processing,Garment and Laundry etc.

The gas-fired steam boiler adopts the structure of mechanical and electrical integration, with generous appearance, compact structure, less space occupation, convenient transportation and less capital investment. It not only follows the concept of energy conservation and environmental protection, but also meets the thermal energy required by the project. In terms of production and use, this kind of boiler really achieves clean combustion, pollution-free emission, convenient operation and sufficient output.

1, the boiler adopts three return structure, large volume design of combustion chamber, so that the combustion is more sufficient.

2, the use of advanced waveform furnace structure, not only increase the heat transfer area, but also to meet the furnace free expansion after being heated.

3. The pipe adopts screw structure, which strengthens the heat transfer effect.

4, The boiler adopts the wet back structure, the whole plate edge butt weld, high reliability, low maintenance cost.

5. The design of the rear viewing device is easy to observe the combustion condition.

6, design over temperature, over pressure, water shortage, leak detection, flameout and other protection functions, boiler operation is safe and reliable.

7, the boiler packaging has color plate, mirror stainless steel or matte stainless steel three forms, beautiful appearance.

8. Equipped with burner with good automatic control performance to realize full automatic operation.

9. Boiler has high thermal efficiency, stable output and strong load adaptability.
