3 Ton 3000kg Horizontal Gas Oil Fired Steam Boiler For Candy Factory,Sugar Factory
3 Ton 3000kg Horizontal Gas Oil Fired Steam Boiler For Candy Factory,Sugar Factory
3 Ton 3000kg Horizontal Gas Oil Fired Steam Boiler For Candy Factory,Sugar Factory
3 Ton 3000kg Horizontal Gas Oil Fired Steam Boiler For Candy Factory,Sugar Factory
3 Ton 3000kg Horizontal Gas Oil Fired Steam Boiler For Candy Factory,Sugar Factory
3 Ton 3000kg Horizontal Gas Oil Fired Steam Boiler For Candy Factory,Sugar Factory
3 Ton 3000kg Horizontal Gas Oil Fired Steam Boiler For Candy Factory,Sugar Factory
3 Ton 3000kg Horizontal Gas Oil Fired Steam Boiler For Candy Factory,Sugar Factory
3 Ton 3000kg Horizontal Gas Oil Fired Steam Boiler For Candy Factory,Sugar Factory
3 Ton 3000kg Horizontal Gas Oil Fired Steam Boiler For Candy Factory,Sugar Factory
3 Ton 3000kg Horizontal Gas Oil Fired Steam Boiler For Candy Factory,Sugar Factory
3 Ton 3000kg Horizontal Gas Oil Fired Steam Boiler For Candy Factory,Sugar Factory
Specifications
Brand Name :
Jinzhen Boiler
Model Number :
WNS3-1.25-YQ
Certification :
IS0900
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
80 set per month
Delivery Time :
5-8 working days
Packaging Details :
Steam Boiler in nude package, but covered with water-proof covering, accessories in plywood case
steam capacity :
3ton/h, 3000kg/h
Pressure :
0.7/1.0/1.25mpa
Steam Temperatur :
170/184/194C
Material :
Q245R Steel Plate
Type :
Natural Circulation
Structure :
Fire Tube
Style :
Horizontal
Thermal efficiency :
92.4%--94.5%
Output :
steam
Suitable fuel :
oil,gas, IPG, city gas
boiler heating area :
30m2
total power :
3.6kw
Description

Industrial Gas oil Diesel fired skid-mounted steam boiler For Textile Industry

General Introduction

WNS series oil/gas fired boiler adopts horizontal three-pass wet-back structure,large corrugated furnace and patented thread pipe technology,equipped with international first-level brand burners and valve groups,and independently developed high-matching PLC control system to realize muitiple linkages.The lock protection function protects the equipment running safely.

It is full-automatic oil(gas) fired packaged steam boiler; adopting horizontal internal micro positive pressure combustion, full wetback design, high efficiency spirally corrugated tubes, fuel economizer and reasonable insulation package; the thermal efficiency can reach more than 90%. Its novel design, rational structural and nice performance achieved perfect quality and nice performance.

Model WNS Series Oil Gas Steam Boiler
Structure Wet Back Fire Tube Packaged Three Pass
Fuel oil, gas, light oil, heavy oil, natural gas, lpg, lng, cng, diesel, biogas etc
Capacity 1-20 ton per hour
Pressure 0.7/1.0/1.25/1.6 Mpa (7/10/12.5/16 Bar)
Temperature 170/184/194/204 Celsius
Application Chemical, food and brewery, pharmaceutical, package plant, textile dyeing and printing industry, swimming pool, hospital,school,clothing industry etc.

Boiler characteristics

1, the overall structure is reasonable, compact, belongs to the boiler island type, in line with the fast loading factory conditions.Boiler host, chimney and pipeline system, in which the host and the chimney section has been made in our factory finished, the host pipe valves, instrument has form a complete set of random loading, shipped to the site will be the host and the chimney can be assembled. The scene test. Just by turning on the air supply, power supply, the water greatly shorten installation period, and can guarantee the quality of the product.

2, design performance is advanced. The host belongs to the whole structure of the boiler, burner assembly before smoke box lid, the main heating surface arrangement and combustion chamber parts. The features of reasonable structure, compact, low steel consumption, furnace with offset waveform furnace, thermal insulation layer choose new lightweight heat insulation material, outer packing USES color sheet, appearance packaging for the rectangle, the boiler performance, weight, structure size and appearance modelling and compared with the capacity of the domestic product has obvious advancement and the look and feel. The boiler feed water equipment in the boiler on the right side of the base and the host, not the other do.

3. Simple water circulation, reasonable structure of pressurized parts, and safe operation under the condition of ensuring water quality.

4, complete auxiliary machinery, advanced comprehensive technical performance.

Technical Parameter

Model Rated Rated Rated Thermal Fuel Consumption Equipment Power Weight

Capacity

(t/h)

Pressure

(Mpa)

Temperature

(C)

Efficiency

(%)

Light oil

(Kg/h)

Natural gas

(Nm³/h)

Burn

light oil

Burn

gas

 (t)
WNS1 1 0.7/1.0/1.25 170/184/194 >90 45-100 18-100 1.5 1.5 4
WNS1.5 1.5 >90.2 101.73 123.47 2.2 1.5 5
WNS2 2 1.0/1.25/1.6 184/194/204 >90.2 137.09 165.97 2.2 3 8
WNS3 3 >91 205.75 249.6 7.5 7.5 9
WNS4 4 >91 272.3 329.5 9 7.5 13
WNS5 5 >91.5 134-402 80-500 17.2 15 15
WNS6 6 >91.5 134-402 80-500 15 15 17
WN8 8 1.25/1.6/2.5 194/204/225 >91.6 523.4 631.5 26 22 21
WNS10 10 >91.6 212-890 150-1085 26 22 22
WNS12 12 >91.8 915.5 1090 26 22 27
WNS15 15 >91.8 931.5 1094.4 / / 34
WNS20 20 >92 1380.33 1598.44 / / 45
Note: Parameter is for reference only, we can design the boilers based on customers’ needs.

Executive Standard

1. Design, manufacture, assembly, experiment and acceptance of boilers in strict accordance with national and industrial standards, including but not limited to the following standards: GB/T16508 Boiler Shell Boiler, TSG G0001 Boiler Safety Design Supervision Code, GB50273 Boiler Installation Engineering Construction and Acceptance Code

2. The main steel used in the boiler is 20 GB/T3087, which ensures the safety and reliability of the boiler.

3. Welding materials shall be selected according to NB/T47018. Full penetration welding with argon protection shall be performed on the boiler tube.

Application

Disel fired steam boiler is being widely used in hospitals, schools, textile mills, garment factories, large supermarket, garment factories, dyeing factory, hotel, dining room, dining room, swimming pool, food factory, beverage factory, soy products, meat products factory, cannery, brewery, pharmaceutical factory, packing plants, building materials factory, paint factory and other places of the enterprises and institutions.

3 Ton 3000kg Horizontal Gas Oil Fired Steam Boiler For Candy Factory,Sugar Factory3 Ton 3000kg Horizontal Gas Oil Fired Steam Boiler For Candy Factory,Sugar Factory3 Ton 3000kg Horizontal Gas Oil Fired Steam Boiler For Candy Factory,Sugar Factory3 Ton 3000kg Horizontal Gas Oil Fired Steam Boiler For Candy Factory,Sugar Factory

FAQ
1. What are the available fuel for the oil gas fired boiler?

Oil gas fired boiler could burn both liquid fuel and gaseous fuel. The liquid fuel could be heavy oil, light oil, diesel, furnace oil, bunker oil, LPG (liquefied petroleum gas), etc. The gaseous fuel could be natural gas, city gas, bio-gas, etc.

2. Whether the boiler can burn dual fuel or multi-fuel?

boiler have oil burner, gas burner, and oil&gas dual fuel burner, we can offer the specific burner based on customers’ requirement.

3. What is the thickness of combustion chamber?

the thickness of corrugated furnace is different based on working pressure and furnace diameter, generally, the thickness is between 10~18mm, large combustion space, and combustion sufficient.

4. What is the inlet pressure of gas burner?

The inlet gas pressure is different for different capacity boiler, for example, the pressure for 2 ton steam capacity boiler is about 8~10KPa, while for 4 ton steam capacity boiler is about 18~20KPa.

5.The brand of burner?
The brands of burner are Italy Baltur, Rellio, Elco, etc.
