500kg/H Factory Direct Supply Industrial Oil/Gas-Fired Steam Boiler Machine For Beekeeping

WNS series gas/oil fired industrial steam boiler use international most mature three-pass all wet back structure,safety and reliable .Use waveform furnace ,strengthens the disturbance of the smoke and increases the radiation heat transfer area ;increases the stiffness of the furnace and effectively reduces the thermal stress of the furnace;enhance heat transfer and promote the combustion of fuel in the furnace.The heating surface is arranged symmetrically with solid structural strength and reasonable water circulation .Boiler up part inside has full water capacity ,big steam space and good quality steam .During procession ,the water level fluctuation is small .Big distance between two ends boiler ,big diameter of tubes ,all of these ensure good natural circulation . Steam boiler with very small heat loss because of unique furnace and flue gas thermal surface design.

It is full-automatic oil(gas) fired packaged steam boiler; adopting horizontal internal micro positive pressure combustion, full wetback design, high efficiency spirally corrugated tubes, fuel economizer and reasonable insulation package; the thermal efficiency can reach more than 90%. Its novel design, rational structural and nice performance achieved perfect quality and nice performance.

Boiler Advantage

1. High Efficiency boiler

1) Equipped with specific burner, high automation and combustion efficiency, low NOx emission.

2) Increases the layout of horizontal fins and vertical fins based on the boiler capacity, combustion gas flows among the water tube bundle at a high speed, excellent heat convection and fast heat transfer efficiency.

3) By equipping with economizer, make full use of the heat of flue gas, decrease the exhaust smoke temperature, the thermal efficiency increase to as high as 96%.

2. Full Automatic Control

1) The burner is full automatic, stable operation.

2) Full automatic interlock protection program, has the protection function of water shortage, over pressure, over temperature, gas leakage, flame out, electric leakage, and phrase-lacking or overloading of motor, etc.

3. High Safety Performance

1) Complete gas manifolds and protection system, including filter, pressure regulating valve, and solenoid valve, etc., to ensure the safety performance of fuel.

2) Reliable boiler auxiliaries and multiple safety protection devices, such as pressure controller, pressure transmitter, water level alarm, safety valve, etc.

4. High Quality

1) All the materials has quality certificate, uses full automatic CO2 welding, NDT test and hydraulic pressure will be done for all boilers to ensure the quality.

2) The preheater uses seamless steel pipes, which are treated by sand blasting and hot-dip galvanizing, lengthen the working life.

5. Centralized Control

Several boilers could be used in parallel, and controlled centrally. Moreover, the centralized controller could record the downtime, location, evaporation capacity, fuel consumption, water volume, steam pressure, water tube temperature, exhaust smoke temperature, etc.

Steam Boiler Specification

When industrial steam boiler goes out of the factory, it is composed of three parts: the main boiler, the chimney and the pipeline system. The main body and the chimney have been manufactured in the factory, and the supporting pipeline valves and instruments of the main boiler have been installed randomly, and then transported to the site to assemble the main body and the chimney.On the spot connect the air source, power supply and water pipeline to start the test.Greatly shorten the installation cycle, and can guarantee the quality of boiler.

Safety control system
We design the safety interlock system with multiple protection and alarm functions
- Protection program of automatic ignition
- Locking and protection program of operation
- Protection program of extinction
- Protection program of completion
- Protection program of water pumps (pressure loss)
- Protection program of ignition failure
- Protection program of combustion engine malfunction
- Protection program of combustion engine flameout
- Sound-light alarm of high pressure
- Sound-light alarm of high limit water level
- Sound-light alarm of low limit water level
- Sound-light alarm of super-high temperature of hot water

Gas/oil fired steam boiler is widely used in hospitals, schools, textile mills, garment factories, large supermarket, garment factories, dyeing factory, hotel, dining room, restaurant, food factory, beverage factory, soy products, meat products factory, cannery, brewery, pharmaceutical factory, packaging plant, building materials factory, paint factory, swimming pool and other places of the enterprises and institutions.
