Silver / Red Analog Ring Down Phone Vandal Resistant Courtesy Hotline Telephones
Silver / Red Analog Ring Down Phone Vandal Resistant Courtesy Hotline Telephones
Silver / Red Analog Ring Down Phone Vandal Resistant Courtesy Hotline Telephones
Silver / Red Analog Ring Down Phone Vandal Resistant Courtesy Hotline Telephones
Silver / Red Analog Ring Down Phone Vandal Resistant Courtesy Hotline Telephones
Silver / Red Analog Ring Down Phone Vandal Resistant Courtesy Hotline Telephones
Specifications
Brand Name :
J&R
Model Number :
JR201-FK
Certification :
CE, FCC, RoHS, ISO9001
Place of Origin :
Shenzhen, China
MOQ :
1 set
Price :
Reconsideration
Payment Terms :
L/C, T/T
Supply Ability :
3000 sets per month
Delivery Time :
3-5 working days
Packaging Details :
pearl cotton, carton
Auto-dial :
Yes
Handset Holder :
Yes
Powered :
Phone line powered
Dimension :
240 *100 *106 (mm)
Gross Weight :
3 KG
Armored Cord :
Yes
Magnetic Hook :
Yes
Weather protection :
IP55-IP65
Color :
Grey, Yellow, Red
Material :
Cold Rolled Steel
Description

Vandal Resistant Analog Ringdown Phone, Courtesy Hotline Telephones

This Vandal Resistant Hotline Telephone with armored cord is housed in robust cold rolled steel box and manufactured to a high standard, it is offer increased resistance to vandalism, and ensure that the primary function of communications is maintained at all times, resulting in a highly reliable product with a long MTBF.

APPLICATIONS

Ideal for Railway applications, Marine applications, Tunnels. Underground Mining, Firefighter, Industrial, Prisons, Jail, Parking lots, Hospitals, Guard Stations, Police stations, Bank halls, ATM machines, Stadiums, inside and outside building etc.

MAIN FEATURES

- Standard Analogue phone

- Robust housing, constructed of stainless steel

- Vandal resistant handset and armored cord

- Wall mounting, simple installation

- Weather proof protection: up to IP65

- Programmable for auto-dial

- External power supply or PoE (SIP)

- RJ45 Port for SIP connection

- Inductive coupler fitted as standard for hard of hearing

- CE, FCC, RoHS, ISO9001 compliance

TECHNICAL PARAMETERS

Analogue Version
Power Supply From the analogue telephone network
Supply Voltage 24 VDC to 65 VDC
Supply Current 20 mA DC to 100 mA DC
Ringer Volume - 80dB(A) at a distance of 1 m
- 110dB(A) at a distance of 1 m (for external horn speaker)
Dialing Method DTMF mode in accordance with ITU-T recommendation Q.23.

Ambient conditions
Protection type IP 66 as per EN60529
Operating temperature -40°C to +70°C
Storage temperature -45°C to +85°C

PACKAGE

unit size: 240 *100 *106 (mm)

Carton size: 340 *235 *165 (mm)

Packaging materials: pearl cotton, carton

Net weight: 2 KG

Gross weight: 3 KG
