SCS 60 Ton Automatic Pitless Road Weighing Bridge Machine , Truck Mounted Scales
SCS 60 Ton Automatic Pitless Road Weighing Bridge Machine , Truck Mounted Scales
SCS 60 Ton Automatic Pitless Road Weighing Bridge Machine , Truck Mounted Scales
SCS 60 Ton Automatic Pitless Road Weighing Bridge Machine , Truck Mounted Scales
SCS 60 Ton Automatic Pitless Road Weighing Bridge Machine , Truck Mounted Scales
SCS 60 Ton Automatic Pitless Road Weighing Bridge Machine , Truck Mounted Scales
SCS 60 Ton Automatic Pitless Road Weighing Bridge Machine , Truck Mounted Scales
SCS 60 Ton Automatic Pitless Road Weighing Bridge Machine , Truck Mounted Scales
SCS 60 Ton Automatic Pitless Road Weighing Bridge Machine , Truck Mounted Scales
SCS 60 Ton Automatic Pitless Road Weighing Bridge Machine , Truck Mounted Scales
SCS 60 Ton Automatic Pitless Road Weighing Bridge Machine , Truck Mounted Scales
SCS 60 Ton Automatic Pitless Road Weighing Bridge Machine , Truck Mounted Scales
Specifications
Brand Name :
KEDA
Model Number :
SCS-60T
Certification :
ISO CE
Place of Origin :
Guangdong, China
MOQ :
1 set
Price :
USD9800~14500
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
200 Set/Sets per Month
Delivery Time :
10~25 days
Packaging Details :
The platform of weighbridge is nude packed and the accessories are packed in cartons or wooden box
Product name :
Industrial Weighbridge
Power supply :
220V/50HZ, AC/DC
Display type :
KELI or YAOHUA
Type :
Digital type
Capacity :
60 Ton
Accuracy :
10KG
Overload protection :
150%F.S
Material :
8~20mm steel Q235
Structure :
U beam girders with 6pcs and 6mm thickness
Load cell :
KELI or Zemic with OMIL certificated
Use :
Heavy Goods
Item :
Weighbridge
Display :
LED/LCD
Features :
High precision and stable performance
Warranty :
1 Year
Description

SCS 60 Ton Automatic Pitless Type Road Weighbridge Machine / Weighbridge Truck Scale

Advantages of Digital Weighbridge

  1.  Strong transmission signal and no interference
  2.  Reduced unbalanced loading due to temperature and creeping due to time
  3.  Auto-diagnosis on failure,error code prompt function,very convenient in calibration and repair
  4.  Digital signal transmission avoiding man-made interference and cheating
  5.  PCB in the sensor has a lightening-protection design,prevents the lightening-protection of the whole system

Technical parameter
Accuracy class OMIL III
Weighing range 10~120(t)
Safe overload 150%F.S
Material Q235
Thickness 8, 10, 12, 14mm (optional)

Structure

U shape bridge construction stucture (6mm thickness)

Painting

Anti rust and anti corrosion painting
Length 5~24(m)
Width 3m,3.2m,3.5m,4m
Safe overload 150%Max
Input voltage 110V±10%~220V±10%,AC
Input power frequency 50Hz,60Hz
Power consumption 12V,DC
Serial port RS232 or RS485 are available to for computer interface and scoreboard interface
Printer interface compatible parallel port
Relative humidity <95%
Working temperature

indicatior: -10+45 centigrade

weighing platform and load cell: -30+65 centigrade

Function:

  1.  Communication interface RS485 and RS232 (PC)
  2.  Error information indication
  3.  EMC protection measurement
  4.  Auto-corner adjustment and manually corner adjustment function
  5.  Printing: standard parallel print interface; filled type bill format can be optional
  6.  Memory: able to save 256 vehicle ID and corresponding tare eight, 256 weighing records
  7.  Two-stage division, two-stage capacity can be selected
  8.  Non-linearity calibration function, daily report printing; timing turn off function
  9.  Separate calibration of the design and operation parameters
  10.  Time: auto leap year, leap month, can display year/month/date/hour/minute/second
  11.  Display: 6 bits VFD, 6 state indication symbols
  12.  Keyboard: Data key: 0~9; function key: 20 pieces (9 of them are same as data key)
  13.  Scoreboard screen display interface: serial output mode and current loop, 11 bits binary number, 600 baud rate
  14.  Printer interface, recommend Epson LQ-200K, Epson LQ-300K+II, KX-P1121, KX-P1131

SCS 60 Ton Automatic Pitless Road Weighing Bridge Machine , Truck Mounted Scales
