Specifications
Brand Name :
Keda
Model Number :
SCS-30T
Certification :
ISO
Place of Origin :
Guangdong, China
MOQ :
1 set
Price :
Negotiated price
Payment Terms :
L/C, T/T
Supply Ability :
200 Set/Sets per Month
Delivery Time :
10~25 days
Packaging Details :
The platform of truck bridge is nude packed and the accessories are packed in cartons
Safe overload :
150% F.S
Material :
Q235 Steel platform
Structure :
U-Beams
Power supply :
220V AC or 9V DC
Capacity :
80Ton
Accuracy :
20kg
Warranty :
12 months
Description

SCS-30T Industrial Vehicle Weight Scales with Computer Interface

Weighbridge technical parameters:

Truck scale width: 3m 3.2m 3.4m

  •  Truck scale length: 6m 7m 8m 9m 10m 12m 14m 16m 18m 20m 21m 24m
  •  Weighing scope: 1t~200t
  •  Accuracy class: OIML III, dynamic,0.5 - 0.2%.
  •  Inside resolution: 1000000
  •  Converting speed: A/D, 500 Times/SEC
  •  Weighing way: vehicle or axis measurement
  •  Load cell: excitation voltage +10V
  •  Remote transmission characteristics: no influence within 100 meters
  •  Environmental temperature: load cell, -20 - +40°C;
  •  weighing indicator: 0 - +40°C
  •  Environmental humidity: <90% RH, without dew
  •  Power supply: 220V(AC)+10%, 50Hz; 12V(DC), 500mA
  •  Rated power: <20W
  •  Display mode: 6 fluorescence display,
  •  16 matrix liquid crystal display
  •  Indicator keyboard: skin type 25 key keyboard
  •  Communication interface: Rs232c can be connected to the printer or computer; Rs422 communication interface is optional.
  •  Control output: be able to expand 3 control output
  •  Data storage: 384 weighing record
  •  Data protection: real-time clock, data protection in blackout
  •  Cable length: 30m signal cable
  •  Indicator shell: aluminum closed shell

Recommended dimension for SCS truck scale platform:

Item Type Scs-30 Scs-60 Scs-80 Scs-100 Scs-120 Scs-150
Max weighing Capability 30 60 80 100 120 150
Graduation 5 10 20 20 20 20
Accurancy grade Oiml
Size of platform 3*7 √
3*10 √
3*12 √ √
3*14 √ √ √ √ √
3*16 √ √ √ √ √
3*18 √ √ √
3*20
3.2*12
3.2*14 √ √
3.2*16 √ √ √ √ √
3.2*18 √ √ √ √ √
3.2*20 √ √ √ √
Remarks 1.Other different size or special capacity can be customized according to customers’ needs.
