7.5KW Oil Free Dry Screw Vacuum Pump For Pharmaceutical Processing Industry
7.5KW Oil Free Dry Screw Vacuum Pump For Pharmaceutical Processing Industry
7.5KW Oil Free Dry Screw Vacuum Pump For Pharmaceutical Processing Industry
7.5KW Oil Free Dry Screw Vacuum Pump For Pharmaceutical Processing Industry
7.5KW Oil Free Dry Screw Vacuum Pump For Pharmaceutical Processing Industry
7.5KW Oil Free Dry Screw Vacuum Pump For Pharmaceutical Processing Industry
Specifications
Brand Name :
FUTEN
Model Number :
FDPH 320
Place of Origin :
HEFEI, ANHUI
MOQ :
3 UNITS
Price :
Negotiable
Delivery Time :
30 work days
Material :
Stainless steel, Carbon steel
Color :
Grey, blue, white, etc
Voltage :
380v, 415v, 460v, etc
Motor :
Siemens, ABB, WEG, WNM, etc.
Motor Type :
Normal Motor, Explosion-proof Motor
Description

FDPH 320 In Pharmaceutical Processing Chemical Pump Oil Free Dry Screw Vacuum Pump

MODEL Suction capacity(m3/h) Ultimate vacuum(Pa) Power (KW) Speed (rpm) Inlet size(mm) Outlet size(mm)

Operating liquid

rates(L/min)

 Weight(kg)
FDPH 320 267/320 2.7 7.5/10 2900/3500 50 40 8 280

Specialties
1 Oil-free and water-dry operation, it is providing a clean vacuum
2 No friction between the screw and the pump to ensures the life of the pump
3 Lower cost
4 Single stage design is easy for cleaning
5 The pipeline of pump is short that the gas could be discharge quickly
6 Special coating for handling toxic, corrosive and condensable gases
7 Simple design which is easy for maintenance
8 Low speed operation, low vibration, low noise
9 Mechanical seal is able to avoid leakage

Advantages
1 To compare with common design, the power consumption is reduced by 30% which is saving a lot of utility costs
2 Reduce operating temperature to meet T4 standards
3 It is Improved vacuum volume to increases vacuum
4 Simple design to save installation space
5 Mainly flanged, simplify installation, reduce noise, and reduce coupling error
