Specifications
Brand Name :
SCHNEIDER
Model Number :
TeSys LC1-K CONTACTOR
Certification :
CE
Place of Origin :
FRANCE
MOQ :
1 PCS
Price :
consult best discount
Payment Terms :
T/T, , Western Union,Paypal,, MoneyGram,, L/C
Supply Ability :
1000
Delivery Time :
2-5 days
Packaging Details :
schneider original package
Electricity TypeE :
AC or Dc
Rated Current(A) :
6A,9A,12A
Rated insulation :
690V
Frequency :
50/60 HZ
Application :
Motor Control
Warranty :
12 Months
Description


Schneider TeSys LC1-K Electrical Contactor Switch Ac Contactor Dc Contactor

Application

TeSys K contactors are widely used for industry, infrastructure and building applications such as:

  • Simple control systems
  • Zones sensitive to noise, disturbed mains supplies (silent contactor: LC7K)
  • Suitable for use with programmable controller outputs (low-consumption contactor)

Specific versions for railway ( TeSys S207 ) and electrodomestic (TeSys S335) applications.

Compliance with standards:

  • IEC 60947
  • NF C 63-110
  • VDE 0660
  • BS 5424
  • UL, CSA, CE and CCC certificates

Specifications:

  • Available control circuits: AC, DC, Low-consumption and silent coil
  • Applications: 2.2 kW, 4.5 kW, 5.5 kW in AC3 and AC4
  • Terminal connection types include:
    - Screw clamp
    - Faston connectors
    - Spring terminals
    - Pins for printed circuit boards
  • 1 NO or 1NC contact embedded
  • Available for 1 way motors, 2 way motors (reversing Contactors) and Star Delta pre- wired version
  • Includes full range of control relays in the same design
  • Possibility to extend the amount of auxiliary contacts thanks to additional auxiliary contact blocks
  • Possibility to protect the motor thanks to additional thermal relays LR2K

Type LC1-K06 LC1-K09 LC1-K12
Rated current at AC3 (A) 6 9 12
Rated working current (Ie)A 5 7.5 10
Conventional thermal current(Ith)A 16 20 20
AC-3 Use Group Control Power KW 220V 1.5 2.2 3
380/415V 2.2 4 5
440/500V 3 4 5
660V 3 4 5
Rated working voltage (Ue)V 380 660
Rated insulation voltage (Ui)V 690
AC-3 (6Ie Ie) Electrical life (times) 0.5 10 6
Operation frequency h-1 1200
AC-4 (6Ie Ie) Electrical life (times) 10 10 4
Operation frequency h-1 300
Mechanical life 3 10 6
LC2-D205 Conventional thermal current 6A
Electrical life (times) AC-15(360VA) 0.5 10 6
DC-13(33W)

Schneider TeSys LC1-K Electrical Contactor Switch For Simple Control Systems
Shipping:
1. We will ship most items within 4 working days after the payment is reached.
2. All the goods will be tested before shipment.
3. We can ship to you by DHL/TNT/UPS/EMS/Fedex... Or ship as your requirement.

Best Quality Assurance:
1. We only provide theoriginal new items, 100% make sure the best quality!
2.1 year warrant GUARRANTEE OF QUALITY
