Fanqun Fluid Bed Granulator 150-300kg/H For Food Product
Fanqun Fluid Bed Granulator 150-300kg/H For Food Product
Fanqun Fluid Bed Granulator 150-300kg/H For Food Product
Fanqun Fluid Bed Granulator 150-300kg/H For Food Product
Specifications
Supply Ability :
20kg/Hr to 2000kg/Hr
Payment Terms :
L/C, T/T
Model NO. :
XF
Type :
Fluidization
Xf-20 :
20-25kg/H
Xf-30 :
30-45kg/H
Xf-50 :
55-90kg/H
Xf-150 :
150-300kg/H
Movement Way :
Combined
Type of Flow :
Parallel Flow
Sprayer :
Air-Flowing Type
Appearance of Dried Sample :
Granule, Bulk, Powder
Type of Atomization :
PLC Control
Trademark :
Changzhou Fanqun
Transport Package :
Sea Packing
Specification :
CE
Origin :
Changzhou, China
HS Code :
84199090
Port :
Shanghai, China
Heating Mode :
Steam, Electricity, Natural Gas, Coal
Material Status :
Granule, Powder
Drying Medium :
Superheated Steam, Effluent Gas, Air
Operation Pressure :
Atmospheric Pressure
Structure :
Single Layer
Operational Method :
Continuous
Description

Fluid Bed Dryer for Food Product

Product Description

Customer Question & Answer

Ask something for more details
About XF Fluid Bed
XF fluid bed system consists of air filter, heater, fluid bed, feeder, cyclone, bag filter, high pressure centrifuge fan, operation table and so on. Based on different requirement of different products, either cyclone or bag filter or both could be chosen.

Principle of work
Products are fed into fluidized-bed drier through feeder. Fresh air after filtering and heating is conveyed to the bottom of fluid bed by fan and contacts with solid raw products on distributing plate, There fluidizing and heating exchange are conducted between air and products. Dry products are discharged from outlet to cyclone and bag filter from the top of fluid bed.

Heat source
Steam, electricity or hot air furnace can be used.

Applications
- pharmaceutical product
- chemical
- food
- pressing tablet
- resin
- citric acid
- maize embryo
- animal food

Flow Chart
Fanqun Fluid Bed Granulator 150-300kg/H For Food Product

Model Bed Area
(m2)		 Fan Power
(kw)		 Drying Capacity
(kg/hr)		 Product Temp.
(°C)
XF-20 0.5 11 20-25 40-60
XF-30 1.0 18.5 30-45 40-60
XF-50 2.0 30 55-90 40-60
XF-150 6.0 67 150-300 40-60

Note: customized design is available
