Vertical Interchangeability Split Case IndustrialSlurry Pumps for Low-Viscosity Liquids
Vertical Interchangeability Split Case IndustrialSlurry Pumps for Low-Viscosity Liquids
Vertical Interchangeability Split Case IndustrialSlurry Pumps for Low-Viscosity Liquids
Vertical Interchangeability Split Case IndustrialSlurry Pumps for Low-Viscosity Liquids
Specifications
Brand Name :
Chengdu Yongyi
Model Number :
ZJL
Certification :
ISO9001
Place of Origin :
Sichuan, China
MOQ :
1 set
Price :
USD 500-5000/set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal
Supply Ability :
300 sets per month
Delivery Time :
25 working days after receiveing advance payment
Packaging Details :
Free Fumigation Export Wooden Box
Flow :
6 ~ 364m ³ / h
Head :
6～58m
Color :
Customized
Application :
Sewage, chemical
Warranty :
one year
Installation :
Dry install
Position :
Upright
Description

Vertical Interchangeability Split Case IndustrialSlurry Pumps for Low-Viscosity Liquids

Operation Data

Name ZJL-series Vertical Slurry Pump
Head 4 ~ 60 m
Capacity 6 ~ 364m³/h
Discharge Size 40mm~200mm
Inlet Size 50mm~250mm
Maximal Efficiency 70%
NPSH 1.4m~3.5m
Allowable Max Motor Power 315 kw
Diameter 200mm~470mm

Advantages

Technical Superiority
• in accordance with theory of two-phase fluids
• Wet parts are made of abrasion-resistant metal
• compact and self contained, installation costs are reduced with minimal foundation requirements.

Process Reliability
• easy replacement due to standardization
• Geometrical shape of its flow passage components is suitable for flow condition of medium

Easy Maintenance
• mechanical seal replacement without motor lantern dismantling
• optional: cartridge seals

Inatallation Dimension

Vertical Interchangeability Split Case IndustrialSlurry Pumps for Low-Viscosity Liquids

Application

They are designed for delivering abrasive, large particle and high-density slurries and applied over the fields such as metallurgy, mining, coal, power, building materials, and environmental protection.

Vertical Interchangeability Split Case IndustrialSlurry Pumps for Low-Viscosity Liquids

FAQ

Vertical Interchangeability Split Case IndustrialSlurry Pumps for Low-Viscosity Liquids

Q: What's your advantage of pumps?
A: We can customised the products according to customers' requirement, develop a proposal and a series of after-sale service.

Q: How about the warranty of your pumps?
A: One year from the date which the pump shiped out from our factory, except the wet end.

Q: Do you inspect the finished product?
A: Yes, each batch of production and finished product will be quality checked strictly before delivering , testing report or video can be sent to clients.

Q: How do you ship the finished product?
A: By sea. By air. By international express.
If you have another question, pls feel free to contact us as below

Vertical Interchangeability Split Case IndustrialSlurry Pumps for Low-Viscosity Liquids
