Double Helical 7.5kw Ribbon Blender Mixer
Double Helical 7.5kw Ribbon Blender Mixer
Double Helical 7.5kw Ribbon Blender Mixer
Double Helical 7.5kw Ribbon Blender Mixer
Double Helical 7.5kw Ribbon Blender Mixer
Double Helical 7.5kw Ribbon Blender Mixer
Double Helical 7.5kw Ribbon Blender Mixer
Double Helical 7.5kw Ribbon Blender Mixer
Specifications
Brand Name :
YIGAN
Model Number :
WLDH
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 set
Price :
negotiation
Supply Ability :
30 sets per month
Delivery Time :
20 working days after received your payment
Packaging Details :
Packed in film firstly, and then reinforced with wooden case for outer packing
product name :
industrial ribbon mixers/industrial powder mixer
mixer type :
horizontal
feature :
stirring paddle
mixing type :
wet mixer
processing object :
powder mixer
structure :
mixing paddle
Description

WLDH-0.5 powder double helical horizontal industrial ribbon mixers

Double Helical Ribbon Blender Mixer , Horizontal Industrial Ribbon Mixer Machine WLDH-0.5

Description

WLDH-0.5 powder double helical horizontal industrial ribbon mixers is composed of container, screw stirring paddles and transitional parts; the screw paddle are generally made into 1 layer or 3 layers, the outer screw converge is the material to the centre front two sides, and the inner layer of screw conveys the material to the two sides from the centre, so as to form convection mixing. The cubage can be made into rotundity, so the jacket can be played in reaction and drying.

Application

WLDH-0.5 powder double helical horizontal industrial ribbon mixers is generally used in the mixing of viscous or adhesive powder material, or the mixing of powder which needs to add liquid, and paste material. Meanwhile, because it is difficult to clean viscous material, the machine is suitable for the mixing case, where the output is large and there is no need of displacing material variety frequently.

Double Helical 7.5kw Ribbon Blender Mixer

Features

a. Less influence on particle size and density

b. Good mixing effect for different viscosities

c. Wide application, strong adaptability

d. SS ribbon, mirror polishing, easy to clean

e. Large discharging outlet, manual or pneumatic valve discharging, to ensure smooth discharging and less residual

Technical Parameters

Model Volumem3 InputcapacityL/batch Totalpowder(kw) Weight (kg) Overalldimension(mm)
WLDH-0.1 0.1 30-50 3 300 1190×740×770
WLDH-0.3 0.3 100-150 4 500 2030×630×980
WLDH-0.5 0.5 200-300 7.5 900 2320×730×1130
WLDH-1 1 400-600 11 1400 2800×920×1320
WLDH-1.5 1.5 600-900 11 1900 3180×1020×1550
WLDH-2 2 800-1200 15 2500 3310×1120×1640
WLDH-3 3 1200-1800 18.5 3100 3750×1290×1820
WLDH-4 4 1600-2400 30 3600 4220×1400×1990
WLDH-6 6 2400-3600 37 5300 4700×1610×2260
WLDH-8 8 3200-4800 45 6800 4420×2150×2470
WLDH-10 10 4000-6000 55 8900

Note:Thisseriesisdesignedaccordingtothevolume.Fordifferentmaterials,themixcapacityisdifferent.onlyforreference.
